3
Getting Ready
Connecting the Equipment
* To prevent malfunction and equipment failure, always turn down the volume, and turn o all the units before making any connections.
DC IN jack
Connect the included AC
adaptor here.
* Place the AC adaptor so the
side with the indicator faces
upwards. The indicator will
light when you plug the AC
adaptor into an AC outlet.
Turning the Power On/O
This turns the power on/o.
* Before turning the unit on/o, always be sure to turn the volume down. Even with
the volume turned down, you might hear some sound when switching the unit on/
o. However, this is normal and does not indicate a malfunction.
Auto O Function
The power to this unit will be turned o automatically after a predetermined
amount of time has passed since it was last used for playing music, or its buttons
or controls were operated (Auto O function). If you do not want the power to be
turned o automatically, disengage the Auto O function.
* Any settings that you are in the process of editing will be lost when the power is
turned o. If you have any settings that you want to keep, you should save them
beforehand.
* To restore power, turn the power on again.
For details on the settings, refer to “Reference Manual” (PDF).
(USB) port
Use a commercially available USB 2.0 cable to
connect this port to your computer. It can be
used to transfer USB MIDI and USB audio data.
You must install the USB driver when
connecting the unit to your computer.
Download the USB driver from the BOSS
website. For details, refer to Readme.htm which
is included in the download.
http://www.boss.info/support/
For details on the settings, refer to
“Reference Manual” (PDF).
SEND/RETURN jacks
Indicator
Connect an external eect
processor here.
GUITAR INPUT jack
Use this control if you’re directly
inputting a conventional guitar.
* If you use a 1/4” phone
plug to make connections,
instruments other than
DYNAMIC SYNTH and the
alternate tuning function will
not operate.
GK IN connector
Connect a guitar or bass equipped with the Roland Divided
Pickup (Roland GK-3/GK-3B) or a GK-compatible guitar such as
the Roland V-Guitar GC-1 to this connector.
In addition to the signal from the divided pickup, the
conventional guitar signal (normal pickup) is also input to the
GK IN connector.
* Never connect anything other than the dedicated GK cable.
Roland GK-3 users Roland V-Guitar GC-1 users
You must set this to the center (MIX) position!
