H2O DMX PRO System Menu
2. Either “ON” or “OFF” will now be displayed. Press the UP or
DOWN buttons to select “ON” to keep the LED display on at all
times, or “OFF” to allow the LED display to turn off after 2 min-
utes. Press any button to turn on the LED display again.
3. Press ENTER, and then press and hold the MENU button for at
least three seconds to conrm.
DISP - This will “ip” the LED display
1. Press the MENU button until “DISP” is displayed, press
ENTER.
2. Either “dISP” or “dSIP” will now be displayed. Press the UP or
DOWN buttons to select one or the other.
3. Press ENTER, and then press and hold the MENU button for
at least three seconds to conrm.
MANU - This function will let you manually test the color
wheel, water wave, and dimmer. In this function you can
also manually adjust and set the color wheel, rotation
speed, and dimmer.
1. Press the MENU button until “MANU” is displayed, press
ENTER.
2. Use the UP or DOWN buttons to scroll between “COLO”
(Color), “WAVE” (Water Wave), or “DIMM” (Dimmer). Select the
function you would like to test and press ENTER.
3. Use the UP or DOWN buttons to adjust the values to test/
check the function. Press the MENU button after testing the
functions.
If you would set your desired color, rotation speed, and dimmer,
press the ENTER button after each submenu is adjusted.
“COLO” is displayed, press ENTER. Make your
adjustments using the UP or DOWN buttons until your desired
©American DJ Supply® - www.americandj.com - H2O DMX PRO Instruction Manual Page 9
On-Board System Menu.
The H2O DMX PRO comes with an easy
to navigate system menu. This next section will detail the functions of
each command in the system menu.
To access the main menu press the MENU button. Press the UP or
DOWN buttons until you reach function you wish to change. When you
reach the function you wish to change press the ENTER button. When
a function is selected use the UP or DOWN buttons to change the func-
tion settings. Once your changes are made press the ENTER button,
and then press and hold the MENU button for at least three seconds
to conrm and lock the change into the system memory. If the MENU
button is not pressed and held within eight seconds the xture will
automatically conrm and lock the change into the system memory. To
exit without making any changes press the MENU button.
H2O DMX PRO System Menu
ADDR - DMX Address Setting via control board -
1. Press the MENU button until “ADDR” is displayed, press
ENTER.
2. “X” will now be displayed, “X” represents the displayed address.
Press the UP or DOWN buttons to nd your desired address.
3. Press ENTER to conrm, then connect your DMX controller.
SLND - This will let you set unit as a master or a slave in a
master/slave conguration.
1. Press the MENU button until “SLND” is displayed, press
ENTER. Either “MAST” or “SL 1” will be displayed.
2. Press the UP or DOWN buttons until your desired setting is
displayed, press ENTER to conm.
LED - With this function the LED display will turn off after 2
minutes.
1. Press the MENU button until “LED” is displayed, press
ENTER.
©American DJ Supply® - www.americandj.com - H2O DMX PRO Instruction Manual Page 8
