![ADJ Double Phase LED Руководство по эксплуатации онлайн [5/10] 758997](/views2/1990712/page5/bg5.png)
American DJ® - www.americandj.com - Double Phase LED Instruction Manual Page 10American DJ® - www.americandj.com - Double Phase LED Instruction Manual Page 9
Double Phase LED System Menu
ADDR - DMX Address Setting.
1. Press the either the MENU, UP, or DOWN buttons until
“ADDR” is displayed, press ENTER.
2. “1” will now be displayed and ashing. Press the UP or
DOWN buttons to nd your desired address. Leave the display
on this address, and after a few seconds the address will be
saved into memory.
CHND - This will let select your desired DMX channel
mode.
1. Press the either the MENU button until “CHND” is displayed,
press ENTER. Either “1CH” or “6CH” will be displayed
2. Press the UP or DOWN buttons to nd your desired DMX
mode and press ENTER to conm and exit.
SLND - This will let you set unit as a master or slave in a
master/slave conguration.
1. Press the either the MENU button until “SLND” is displayed,
press ENTER. Either “SL 1” or “SL 2” will be displayed.
2. Press the UP or DOWN buttons until your desired setting is
displayed, press ENTER to conm and exit.
SHND - Show modes 0-8 (Factory programs). In show mode
the unit can run with either sound activity on or off.
1. Press the MENU button until “SHND” is displayed, press ENTER.
2. “Sh X” will now be displayed, “X” representing a number
between 0-8. Programs 1-8 are factory programs, while “Sh 0”
is random mode. Press the UP or DOWN buttons to nd your
desired show.
3. Press the ENTER button, to select your desired show speed.
4. Once you have selected the show speed press ENTER and
then press and hold the MENU button for at least 3 seconds to
conrm.
SOUN - In this mode you can run the unit in sound active
mode. A show must be selected before the unit will run in
sound active mode.
1. Press the MENU button until “SOUN” is displayed, press ENTER.
2. Either “ON” or “OFF” will now be displayed. Press the UP or DOWN
buttons to select one or the other.
3. When you have made your selection, press the ENTER, and then
press and hold the MENU button for at least 3 seconds to conrm.
SENS - Using this mode, you can set the sound sensitivity
level. 0 for least sensitive, 100 for most sensitive.
1. Press the MENU button until “SENS” is displayed, press ENTER.
2. Using the UP or DOWN buttons adjust the sensivity level to your
desire.
3. When you found your desired level, press the ENTER, and then press
and hold the MENU button for at least 3 seconds to conrm.
BLND - Blackout or Stand by mode.
1. Press the either the MENU button until “BLND” is displayed,
press ENTER. Either Yes or No will be displayed.
2. To activate Blackout tap the UP or DOWN buttons until Yes is
displayed, press ENTER to conm and exit. The xture will now
be in Blackout mode. To deactivate Blackout mode, select No
and press Enter.
Double Phase LED System Menu
