American DJ® - www.americandj.com - Double Phase LED Instruction Manual Page 13 American DJ® - www.americandj.com - Double Phase LED Instruction Manual Page 14
Operating Modes: The Double Phase LED three operating
modes.
• Sound Active Mode -
The unit will react to sound, chasing through the built-in programs.
The sound sensitivity is adjustable.
• Show Mode -
Run 1 of 8 preset shows.
• DMX control mode -
This function will allow you to control each individual fixtures traits
with a standard DMX-512 controller such as the Elation® Show
Designer.
™
Universal DMX Control: This function allows you to use a
Elation® universal DMX-512 controller to control the chases and
patterns, dimmer and strobe. A DMX controller allows you to create
unique programs tailored to your individual needs.
1. The Double Phase LED has two DMX Channel modes. A 1 chan-
nel mode and a 6 channel mode. To set the channel mode see
page 9. See pages 16-17 for detailed description of the DMX
traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 5-7 as well as the set-up specifications that are
included with your DMX controller.
3. Use the controller’s faders to control the various DMX fixture traits.
4. This will allow you to create your own programs.
5. Follow the instruction on page 9 to set the DMX address.
6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
7. For help operating in DMX mode consult the manual included
with your DMX controller.
Sound Active Mode: This mode allows either single unit or several
units linked together, to run to the beat of the music.
1. Press the MENU button until “SOUN” is displayed, and press
ENTER. Press the UP or DOWN buttons so that “ON” is displayed
and press ENTER. The unit is now sound active.
See page 10 for sound sensitivity adjustment.
2. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Double Phase LED Operation
Double Phase LED Operation
Show Mode: In this mode you can choose 1 of 8 shows to run.
1. Tap the MENU button until “SHND” is displayed, and press
ENTER.
2. Tap the UP or DOWN buttons until you nd your desired show,
and press ENTER then press and hold MENU for 3 seconds to
con rm. See page 9 for more info.
3. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Master-Slave Operation: This function will allow you to link up to 16
units together and operate without a controller. The units will be sound
activated. In Master-Slave operation one unit will act as the controlling
unit and the others will react to the controlling units programs. Any unit
can act as a Master or as a Slave.
1. Using approved DMX data cables, daisy chain your units togeth-
er via the XLR connector on the rear of the units. Remember the
Male XLR connector is the input and the Female XLR connector
is the output. The rst unit in the chain (master) will use the female
XLR connector only - The last unit in the chain will use the male
XLR connector only. For longer cable runs we suggest a termina-
tor at the last fixture.
2. On the Master unit find your desired show and set that show by
pressiing the ENTER button.
3. On the slave units tap the MENU button until “SLND” is displayed,
and Press ENTER. Choose either “SL 1” or “SL 2” and press
ENTER. See page 9 for more info.
4. The slave units will now follow the Master unit.
5. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
