![ADJ BOOM BOX FX3 [5/14] Boom box fx3 rear layout](/img/pdf.png)
ADJ BOOM BOX FX3 [5/14] Boom box fx3 rear layout
![ADJ BOOM BOX FX3 [5/14] Boom box fx3 rear layout](/views2/1990714/page5/bg5.png)
ADJ Products, LLC - www.adj.com - Boom Box FX3 Instruction Manual Page 9ADJ Products, LLC - www.adj.com - Boom Box FX3 Instruction Manual Page 8
Boom Box FX3 Rear Layout
AmericanVersion: EUVersion:
1.FunctionDisplay:Usedtoshowthevariousmenusandtheselectedfunctions.
Button:
MENU
Toselecttheprogramming functions
UP
Togoforwardintheselectedfunctions
DOWN
Togo backward in the selected functions
ENTER
Toconrmtheselectedfunctions
LED:
MASTER On Master mode
SLAVE On Slavemode
SOUND On Soundactivation
DMX On DMXinputpresent
2. On/O Switch: Toturnon/othe unit.
3.DMXIN/OUT: ForDMX512 links, use 3‐ pin XLR plug cable to link the unit together.
4.FUSE:(T2A): Protecttheunitfromdamage of over current.
5.POWERIN/OUT :Usedtoconnect to power outlet or next xture.
6.KeyforLaser:Toturnon/othelaser. (OnlyforEUversion)
Boom Box FX3 System Menu
Boom Box FX3 CAD Drawing
23.66”/601mm
22.87”/581mm
8.77”/223mm
8.25”/210mm
25”/634mm
9.15”/232mm
5”/128mm
12.32”/313mm
5.75”/147mm
