ADJ Products, LLC - www.adj.com - Boom Box FX3 Instruction Manual Page 16 ADJ Products, LLC - www.adj.com - Boom Box FX3 Instruction Manual Page 17
Boom Box FX3
Master-Slave Set Up
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 8 xtures maximum @ 120V, and 16 xtures maxi-
mum @ 230V. After the maximum amount of xtures has been
reached, you will need to use a new power outlet. They must be
the same xtures. DO NOT mix xtures.
Boom Box FX3 Power Cord Daisy Chain
Master-Slave Operation This function will allow you to link up to
16 units together and operate without a controller. In a Master-Slave
set up, one unit will act as the controlling unit and the others will react
to the controlling units programs. Any unit can act as a Master or as a
Slave.
1. Using approved DMX data cables, daisy chain your units togeth-
er via the XLR connector on the rear of the units. Remember the
Male XLR connector is the input and the Female XLR connector
is the output. The rst unit in the chain (master) will use the female
XLR connector only - The last unit in the chain will use the male
XLR connector only. For longer cable runs we suggest a termina-
tor at the last fixture.
2. On the Master unit press the MENU button until “SLND” is dis-
played, and press ENTER. Use the UP and DOWN buttons to
scroll to the “MAST” setting and press ENTER.
3. After setting the Master unit to the master setting find and set
your desired operating mode.
4. On the slave units press the MENU button until “SLND” is dis-
played, and press ENTER. Choose either “SL 1” or “SL 2” and
press ENTER. See page 10 for more info.
5. The slave units will now follow the Master unit.
Boom Box FX3
UC IR/Airstream Control
The UC IR (sold separately) infrared remote gives you control of
various functions (See below). To control the fixture you must aim the
remote at the front of the fixture and be no more than 30 feet away.
The Boom Box FX3 is also compatible with the Airstream IR app.
The IR transmitter is available through any ADJ dealer or through the
ADJ parts website. Plug the transmitter into the headphone jack of
your iOS phone or tablet. To control your IR fixture you must raise
the volume to the maximum on your iOS phone or tablet and aim
the transmitter at the front of the fixture and be no more than 15
feet away. After you have purchased the Airstream IR transmitters,
the app is a free download from the app store for your iOS phone or
tablet. The app comes with 3 pages of control depending on the IR
fixture you are using. Please see below for IR functions including the
corresponding app page.
Works with App page 1.
STAND BY - Pressing this button will blackout the fixture. Press the
button again to return to the initial state.
FULL ON - Hold this button down to fully light up the unit. When you
let the button go, the unit will return to its previous state.
STROBE - Not valid for this unit.
FADE/GOBO - Press this button and the press one of the numeral
buttons to select your desired show.
“DIMMER +” and “DIMMER -” - These button’s are invalid for this
fixture.
COLOR - Press this button and the press one of the numeral buttons
to select your desired show.
1-9 - Use buttons 1-9 to select your desired show when show mode
is activated.
SOUND ON & OFF - Use the buttons to activate and deactivate
sound active mode.
SHOW 0 - Press this button to activate show 0 and show mode. Use
buttons 1-9 to select your desired show.
