ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 |v. 09/06/2016 | K01070
8
7.3. Where to Use
The grinder should be installed on a at, stable surface. The minimum
dimensions of the work space should be as follows:
Model
K3 TOUCH, K3 PUSH,
K3 TOUCH ADVANCED
K3 TOUCH, K3 PUSH,
K3 TOUCH ADVANCED
(MINI HOPPER)
Height
20.27
515
17.31
440
in
mm
Width
7.28
185
7.28
185
in
mm
Depth
15.15
385
15.5
385
in
mm
7.4. Grinder Installation
Before grinder installation, the following should be considered:
• The grinder information plaque data coincides with the electrical system on
site.
• The electrical outlet coincides with the grinder plug.
• The electric power at the location of installation should meet the minimum
required to properly run the grinder.
• The installation site should have the proper electrical overload protections.
• The grinder should be properly grounded as specied by local code.
NOTE: The grinder should be used in environments with mínimum temperature
of 77-86F and should not be installed in places (such as industrial kitchens) where
cleaning is done with direct water spray cleaning.
