Compack К3 Touch adv [14/23] Operation
![Compack К3 Touch adv [14/23] Operation](/views2/1996269/page14/bge.png)
ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 |v. 09/06/2016 | K01070
12
8.4. Adjusting the portalter holder clip
It is possible to lower or raise the portalter holder clip ( ) using the Allen Key 2,
which will accommodate the vast majority of portalters found on the market (Fig. 7).
9. OPERATION
9.1. Using the K3 PUSH
The main power switch on the K3 PUSH ( ) has 3 positions, I - 0 - II (Fig. 8).
I
Continuous grind.
0 Off.
II
Push Mode which will grind while the front
activation panel ( ) is pushed in with the portalter.
