Compack К3 Touch adv [12/23] Grind adjustment system

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 |v. 09/06/2016 | K01070

8.2. Grind adjustment system

8.2.1. Micrometrical system

Rotate the grind regulator ( ) until reaching the grind level desired.

Rotating the grind regulator clockwise will result in a courser grind; turning the

regulator counter clockwise will result in a ner grinder* (Fig. 3).

* It is recommended that the motor be running when adjusting to ner grind setting.

This helps to avoid jamming the burrs, which can occur when coffee beans are in the

grind chamber, and the grind regulator is adjusted towards ne.

8.2.2. Stepped Grind adjustment (optional)

In the stepped adjustment versions, the positions on the grind regulator are limited

by “steps” that are dened by the hole and pin points (Fig. 4).

The instructions detailed in section 8.2.1. on adjusting the regulator should be

followed, while at the same time, pulling the brake post ( ) (Fig. 4) up to release the

locking action of the post.

NOTE: If the output is very slow, it could mean that the coffee is being ground too

ne. If the output is very fast, it could mean that the coffee is being ground too

coarse. A perfect espresso grind is found when the grind point gives an infusion of

25 ml of coffee in 25 seconds using 7 grams of ground coffee.
