12000/ Translation of the original instructions

MAINTENANCE SUMMARY TABLE

PROCEDURE EVERY 8

HOURS

AFTER

HOURS

EVERY

HOURS

EVERY

100

HOURS

ONCE A YEAR

OR EVERY 200

HOURS

Engine oil

check the level ●

change ● ●

Air filter

check ●

replace ٭

Gearbox oil

Check the level ●

replace ●

Check that the engine intake grid is

clean

●

Check that tines are well-sharpened

and well-fixed

● ● ٭

Lubricate with grease

●

Check clutch clearance (free play)

● ●

● recommended procedure

٭ procedure to be carried out if necessary

LONG PERIODS OF STORAGE

Store the machine in a dry environment, sheltered from the elements and, if possible, covered up. If the

mower will not be used for a long period (more than one month), disconnect the red battery lead and

follow the directions given in the engine manual; in addition grease all the joints. Check regularly that the

battery voltage has not dropped below 12.5 Volts and if necessary, recharge it.

TRANSPORTING THE MACHINE

If the Rotavator has to be transported on a lorry or a trailer, fasten it to the vehicle using ropes or cables.

IMPLEMENTS

CAUTION: Before fitting the tines assembly or wheel extensions to the tiller shaft (fig. 2A no. 8), check

that the shaft and the inside of the accessory to be mounted are perfectly clean. After having fitted the

accessory to the shaft, tighten the fixing screws thoroughly. The tilling depth can be increased or

reduced by lowering or raising the rear spur. Turn the tip of the spur forward when working in hard,

compacted ground; turn back when the soil is not very firm (fig. 7).

PLOUGHS

The ploughs designed for the rotavator Grillo 12000 (fig. 10) have been especially developed to obtain

good ploughing without over-straining the operator. Two models are available: single furrow plough and

180° roll-over plough. The latter is especially suitable when working forwards and backwards, such as

along rows of vines or fruit-trees. The depth of the furrow may vary from 10 to 15 cm depending on the

soil. The plough must be fitted behind the tiller on the adjustable implement-holder (fig. 8) by simply

removing the spur support, pulling the split-pin and the pin. Then fit the implement-holder and replace

the pin. It is also necessary to remove the two tiller assemblies (fig. 9) then install the wheel extensions

and finally connect the 5.00×10 wheels.
