Grillo 12000 [8/46] Putting the machine into service

12000/ Translation of the original instructions

TECHNICAL SPECIFICATIONS

ENGINE: LOMBARDINI 15LD440, 441 cm³, 10,9 HP, 8,0 kW (@ 3600 r.p.m.), one cylinder diesel.

STARTER: recoil starter or electric starter.

FUEL TANK: 5 litres.

HOURLY CONSUMPTION: 1,8 litres.

CLUTCH: conic and active.

TRANSMISSION: oil bath gears.

GEARBOX: three forward gears and one reverse gear.

P.T.O: one running at the engine r.p.m. in anti-clockwise rotation + one synchronized P.T.O with gearbox

speeds in clockwise rotation.

HANDLEBAR: adjustable in all positions and fitted on anti-vibration blocks.

STANDARD ROTARY TILLER: with 6 tines and side discs for a total width of 990 mm

HOES DIAMETRE: 340 mm.

WORKING AREA without side discs: adjustable at 590 – 860 – 1120 mm (with enlargement kit).

WORKING AREA DEPTH: 330 mm.

ROTARY TILLER RPM: I 82 r.p.m.; II 137 r.p.m. III 191 r.p.m.; I REVERSE 52 r.p.m.

ATTACHMENTS: plough, furrower, wheel extensions, rubber wheels, transfer wheels.

WEIGHT: 118 kg with 15LD440 recoil starter – 131 with 15LD440 electric starter

PUTTING THE MACHINE INTO SERVICE

- Check that the machine has not been damaged during transport.

- Fix the spur (fig. 7).

- Fix the tines' covers (fig. 12).

- Fix the engine support foot where necessary (fig. 2 n. 15).

- Fill in the engine oil tank (see engine handbook).

With the machine in horizontal position, the following checks must be carried out before starting the

engine:

- Check that the gearbox oil level can be seen through the gauge (fig. 3).

- To check engine oil, remove the level check cap following the instructions provided in the engine

handbook.

- Check the oil level in the air filter and make sure it is clean (fig. 4); to fill the filter, use the engine

oil.

- Check that there is little free play on the clutch cable between the adjuster and the lever.

- Fill the tank with fuel, using a funnel with a very fine filter to remove any impurities.

- Ensure that the gear lever is in “neutral” position.
