19
3. DISASSEMBLY & REASSEMBLY
Removing the Freezer Door
PART NAME FIGURE DESCRIPTION
Removing the
Freezer Door
1. After unscrewing and removing two bolts,
disassemble the ASSY HINGE MID (⑥).
2. Remove the door by carefully lifting the door (⑦).
Be careful not to scratch.
