Samsung RB37A50N0SA [21/101] Disassembly reassembly
![Samsung RB37A50N0SA [21/101] Disassembly reassembly](/views2/2003579/page21/bg15.png)
21
3. DISASSEMBLY & REASSEMBLY
PART NAME FIGURE DESCRIPTION
Water
Dispenser
(Frige Option
Item)
1. Hold it at both sides as shown in the picture and
remove it by liftiing it up.
