26
3. DISASSEMBLY & REASSEMBLY
PART NAME FIGURE DESCRIPTION
Evaporator
Cover In
Freezer
1. Pull out all drawers.
2. Remove 3 screws.
3. Pull out the Shelf Fre Upp as far as it goes.
4. Pull out the cover evap with 2 hands from
bottom to top in order.
When diassembling, make sure the unit
turned off.
Fan Motor In
Freezer
1. Remove 3 screws.
2. Disengage 2 housing connectors.
3. Unfasten wires.
