The connections must be performed in compliance with the legal standards in force. Check

that the relief valve and the electrical system are able to support the load of the appliance (see

the technical specifications in point B).

Some types of appliance are supplied with a cable without plug; in this case, “standardised”

plugs must be used, keeping in mind that:

- the yellow-green wire must be used for the earth,

- the blue/white wire must be used for the neutral,

- the brown/black wire must be used for the phase; the cable must not come into contact with

hot parts (over 70° C).

- fit a plug that is suitable for the load to the power cable, and connect it to a suitable power

outlet.

For appliances that come supplied with cable and plug please ensure they are plugged into a

circuit suitable for this appliance.

Please refer to a qualifed person. (See technical specifications in point B).

The manufacturer declines all liability if the safety standards are not observed.

RANGE HOOD WITH OUTSIDE DISCHARGE (exhaust)

In this version, the fumes and steam from the kitchen are conveyed outside through an exhaust

duct. The exhaust conveyor that protrudes from the upper part of the range hood must be con-

nected to a duct that carries the fumes and steam outside. In this version, the charcoal filters,

if fitted, should be removed; to do this, see the instructions in point F. There must be adequate

ventilation of the room when the range hood is used at the same time as appliances burning

gas or other fuels, according to the standard.

Deviation for Germany:

When the range hood and appliances supplied with energy other than electricity are simulta-

neously in operation, the negative pressure in the room must not exceed 4 Pa (4x10 E-5 bar).

RECIRCULATING RANGE HOOD (with filter)

In this version, the air passes through charcoal filters for purification, and is then recirculated

back into the kitchen.

Check that the charcoal filters are fitted to the motor, and if not, install them as described in

the instructions in point H.

If the hood is of filtering type, remove the non-return valve fitted at the motor’s outlet.

For maximum efficiency, the third speed should be used when there are strong odours or a lot

of steam, the second speed in normal conditions, and the first speed for keeping the air clean

with minimum energy consumption. The range hood should be switched on when starting to

cook, and left on until the odours disappear.

OPERATION

ELECTRONIC CONTROL PANEL

Light pushbutton

• ON: light on (the pushbutton is lit);

• OFF: light off;

Pushbutton -

Press to reduce motor speed

Speed 1, 2 and 3 are indicated by the number of LEDs that light up (excluding the light and the

timer LEDs).
