English

Pushbutton +

Press to increase motor speed

Speed 1, 2 and 3 are indicated by the number of LEDs that light up (excluding the light and the

timer LEDs).

(In the 4-speed version the pushbutton + blinks. The fourth speed remains on for a set duration

of time. After 15 minutes the motor returns to the third speed).

Mode pushbutton

Function: it turns hood motor on and off.

The function “desired speed” enables to start the motor at the speed that was selected before

the hood was last turned off.

Optional: version with remote control (some versions only).

WARNING:

Install the hood away from sources of electromagnetic waves, as these could affect the cor-

rect operation of the electronic system.

Maximum operating distance: 5 metres. The maximum operating distance could be less than

5 metres in case of electromagnetic interference by other equipment.

Light pushbutton on remote control: light on/off.

– and + pushbutton: increase/decrease speed (to start the motor press either the + or the –

pushbutton).

Timer pushbutton: see instructions below.

Timer and ‘filter clogged’ alarm pushbutton

• This function allows the automatic turning off of the hood after running for 15 minutes at the

speed previously set (the pushbutton shows a flickering light).

• After about 30 hours of running the pushbutton indicates the need for washing the metal

filters (the pushbutton shows a solid red light). To disable the alarm press the pushbutton

for a few seconds until the red light turns off. Then turn the hood off and on again to check

that the alarm has disappeared.

FILTERS REMOVING AND REPLACING’S INSTRUCTIONS

1. METAL FILTERS

To remove the metal grease filter, open the door carefully as shown in fig. 2. Use the

handle to remove the metal filters.

2. CHARCOAL FILTERS

Remove the metal filters by following the instructions in section H1.

The two filters attached to the right and left hand side of the conveyor can now be easily

accessed. See figure for assembly/replacement.

To order new carbon filters contact your distributor/dealer.

ONLY FOR ITALY: Download the form to order the filter from the website:

www.falmec.com (via the dropdown assistance menu).
