20
GB
1. FOR YOUR SAFETY
Although the machine is simple to use, it is important
that you read the entire booklet before installing or
using the machine for the first time. By doing so, you will
achieve the best performance, avoid mistakes, use the
machine in absolute safety and protect the environment.
During use
• This machine must only be used by adults. Other-
abled persons can use the machine only if there is a
person responsible for their safety that will supervise
and instruct them in the use of the machine.
• Make sure that children do not touch the controls or
play with the machine.
• This machine is intended for home use; another
other use is considered improper and, therefore,
dangerous.
• Always keep the machine clean.
• It is dangerous to modify, or attempt to modify, the
characteristics of this product.
• The exposed parts of this machine get hot during
operation and remain hot for a certain period of time
after it is turned off. Keep children away until the
machine has cooled.
• Do not touch the hot surfaces during use but use the
knobs or handles.
• Make sure the machine is disconnected from the
electric mains before any maintenance or cleaning.
• If the machine breaks, do not try and repair it yourself.
Repairs made by unqualified persons can cause
damage and accidents. Consult the contents of this
booklet. If you don’t find the information you need,
contact the nearest service centre. This machine
must be serviced by an authorised Service Centre.
Always request the use of original replacement parts.
For installation and maintenance
• After unpacking the machine, check that the product
has not been damaged and that the power cord is
in perfect condition. If not, contact the reseller before
operating the machine.
• The packing materials (plastic bags, styrofoam, etc.)
must not be left within the reach of children because
they are potentially dangerous.
• Before use, check that the voltage and power listed
on the machine’s nameplate match the line to which
it will be connected. Also make sure that the building
has an efficient earth line and a suitable circuit
breaker.
• Any service must be performed by specialised
personnel.
• The manufacturer will not be liable if these rules are
not followed.
2. RECOMMENDATIONS FOR THE
PROTECTION OF THE ENVIRONMENT
Packing
All packing materials used are safe for the environment
and recyclable. Please make your contribution to
protecting the environment by disposing of the packing
in the appropriate recycling bins.
Obsolete equipment
• Machines that are obsolete or no longer used should
not be thrown away in the trash. Through ecological
disposal, the various materials used in the production
of your machine can be recovered.
• Ask your specialised reseller or your city administration
about disposal options.
• Before scrapping the machine, cut the power cord to
make it unusable.
It is very important to keep this instruction booklet for
future consultation. If the machine is sold or given to
another person, make sure to give the booklet to the new
user so that they will be informed about the operation of
the machine and the relative warnings.
This symbol on the product or packaging means
that the product must not be thrown away in household
waste but must be taken to a collection point for recycling
electrical and electronic equipment. By disposing of this
product properly, you will avoid potential damage to the
environment and health caused by the incorrect disposal
of the product. For more detailed information about
recycling this product, contact your city administration,
local waste disposal service or the store where you
purchased it.
3. INSTALLATION OF THE MACHINE
“BUILT-IN” INSTALLATION IN MODULAR FURNITURE
For the good operation of the machine when built-
in to modular furniture, the latter must have suitable
characteristics.
In conformity with safety standards, protection against
contact with electrical parts and parts protected with
just functional insulation must be provided through the
correct housing of the machine.
All the parts that provide protection, including any
covering panel (for example, if the machine is positioned
at the end or beginning of the modules), must be
fastened in such a way that they cannot be removed
with the aid of a tool.
It is also a good idea to install the machine at a certain
distance from refrigerators or freezers because the heat
it emits could affect their operation.
