OMNITRONIC CMP-2000 [52/52] Technical specifications
![OMNITRONIC CMP-2000 [52/52] Technical specifications](/views2/2007789/page52/bg34.png)
00074823.DOC, Version 1.0 52/52
14. TECHNICAL SPECIFICATIONS
Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 16 W
Type: dual CD/MP3 player
Available disc: CD/-R/-RW in CD-DA and MP3 format (8 and 12 cm)
D/A converter: 8-fold/1 bit
Sampler frequency: 44.1 kHz
Frame accuracy: 1/75 sec
Pitch adjustment: ±4 %, ±8 %, ±16 % (MP3 CD), ±100 % (audio CD)
Display: ID3 tags, elapsed time, remain time, total remain time
Distortion: 0.008 % (CD), 0.007 % (USB)
S/N ratio: 126 dB (CD), 85 dB (USB)
Frequency range: 17-20000 Hz (CD), 17-16000 Hz (USB)
Audio output: 2 x stereo RCA/ 2 V
Dimensions (LxWxH): 482 x 267 x 89 mm (player units), 482 x 91 x 94 mm (control unit),
Rack installation with 2 U each
Weight: 6.3 kg
Regarding playable discs and files
Playable disc types CD/-R/-RW in CD-DA and MP3 format
Disc writing method Disc-At-Once and Track-At-Once
Multisession
If the first session is CD-DA, only CD-DA tracks can be played.
If the first session is MP3, only MP3 files can be played.
Recording format
ISO9660 max. 63 characters
Joliet max. 63 characters
CD-ROM
sector format
mode 1 only
Supported MP3
formats
MPEG-1 supports Audio Layer-3 (ISO/IEC 1172-3) sampling frequencies
32, 44.1, and 48 kHz, with bit rates (VBR, VRBI, Xing) of 32 to
320 Kbps.
MPEG-2 supports Audio Layer-3 (ISO/IEC 13818-3) sampling frequencies
16, 22.05, and 24 kHz, with bit rates (VBR, VRBI, Xing) of 32 to
160 Kbps.
MPEG-2.5 supports Audio Layer-3 sampling frequencies 8, 11.025, and 12
kHz, with bit rates (VBR, VRBI, Xing) of 32 to 160 Kbps.
File extensions .mp3, .MP3, .mP3, and .Mp3
File systems
FAT 12/16/32
Number of folders max. 255 (CD), max. 999 (USB)
Number of files max. 999; 255 per folder (CD), max. 999 (USB)
System requirements Database Builder
Operating system: Windows XP SP3, Vista SP2, 7 and 8
Minimum hardware requirements: Intel Pentium 4, 1 GHz or better
512 MB RAM
100 MB free disk space
Please note: Every information is subject to change without prior notice. 27.02.2013 ©
