1. Link: sends on output the same signal coming from LINE INPUT connector.

This allow the cascade connection of different devices to the same sound

source.

2. Line input: balanced XLR socket for connection of the signal to be amplified.

3. D.Loud: activates a dynamic equalization of the system, to compensate the

natural sensibility curve of the human ear, which is weaker on low and high

frequencies, when the sound volume is low. The equalization is dynamic,

allowing to regulate continously the amount, according to the signal level,

fading away when the volumes get to the highest levels.

4. H.Pass: activates a High-Pass filter, expressly made to join the speaker

together with a Subwoofer of the SUB series. When this filter is turned off,

the speaker behaves like a full-range speaker, while when the filter is

activated the speaker behaves like a "satellite" of the Subwoofer.

5. AC Power Out: easily connect another VERSE speaker to the mains. Pay

attention not to exceed the limit reported on the chassis near the grey

connector.

6. Mains In: connect the mains cable supplied from the factory with the

loudspeaker to this socket.

7. LEDs:

- ON LED: indicates that the speaker is On.

- Prot. LED: indicates that the internal amplifier switched to protection

mode due to a fault of the amplifier itself or of the connected speakers

(please call the technical support).

- Temp. LED: indicates that the internal amplifier switched to protection

mode due to excessive heating. In this condition, the amplifier supply half

the normal power. Please reduce the input signal to allow the restore of

normal load conditions.

- Comp. H. LED: indicates activity of the High frequency compressor. If the

signal passes over a safety threshold, the compressor guarantees a good

quality playback without acoustic distortion, damping the appropriate signal

frequencies. The system operates in total safety. If the LED is constantly On,

there is an excess of signal. In this case, please reduce the incoming signal

level.

- Comp. L. LED: indicates activity of the Low frequency compressor. If the

signal passes over a safety threshold, the compressor guarantees a good

quality playback without acoustic distortion, damping the appropriate signal

frequencies. The system operates in total safety. If the LED is constantly On,

there is an excess of signal. In this case, please reduce the incoming signal

level.

- Sign. LED: indicates that the signal is present.

8. Gain: to adjust the signal gain in the range from -35dB to 0dB.

9. POWER: Switches the power on/off.
