TASCAM MiNiSTUDIO PERSONAL
15
Opening the Settings Panel
You can use the Settings Panel to make settings for the
various functions of this unit. You can also check the
versions of the firmware and software used by the unit.
You can open the Settings Panel in the following ways.
Windows
Windows 10
• Click the Windows Start button, select “All apps”
and then select “MiNiSTUDIO Settings Panel”
under TASCAM.
Windows 8.1
• You can also left-click the Start button to open the
Start screen, and click the button to open the
Apps screen. On this screen, click “MiNiSTUDIO
Settings Panel” under TASCAM to open it.
Windows 7
• Click the Windows Start button, select “All
Programs” and then select “MiNiSTUDIO Settings
Panel” under TASCAM.
Mac
• Using the Finder, open the Applications folder
and click “MiNiSTUDIO Settings Panel” to open
the Settings Panel.
Settings Panel overview
The Settings Panel has two tabbed pages.
Click a tab at the top of the Settings Panel to open
that page.
• EASY: This shows the current status of the driver
and information about connections.You can also
make various basic settings.
• EXPERT: Make settings for the built-in mixer and
effects, for example, on this page.
NOTE
When you open the Settings Panel, it will open in
the same state as when last closed.
Using the Settings Panel menu bar
Click “Mode Presets”, “Initialize” , “Scene Memory”
or “Extra Effects” at the top left of the menu bar on
either the “EASY” or “EXPERT” tab of the Settings Panel
to open the corresponding menu screen.
8
Mode Presets (Windows only)
i BROADCAST (default)
The settings of this preset are suitable when streaming
a live broadcast from a computer, for example.
i Karaoke
The settings of this preset are suitable for
Internet karaoke, for example.
Set ASIO to “ON” in the Settings Panel if you
want to use compatible VST plug-ins to add
echo or other effects.
When using the MiNiSTUDIO built-in effects, set
ASIO to “OFF” in the Settings Panel.
i Talking
The settings of this preset are for talking using
ordinary Internet audio/video communication
applications, for example.
i Talking with PON/BGM
The settings of this preset are for talking using
ordinary Internet audio/video communication
applications, for example, while using the
built-in PON function or playing background
music from Windows Media Player or another
application.
i Gaming
The settings of this preset are for live streaming
of game play while talking to other players in
games that support voice chat.
i Podcast Multi-channel
The number of ASIO input channels has been
increased to six.
In addition to the Mic inputs (Mixing Driver
In1/2), the output of the “MiNiSTUDIO US-32/42”
Windows Driver can be assigned to Mixing
Driver In3/4 and the output of the “Additional
driver US-32/42” can be assigned to Mixing
Driver In5/6.
When using a DAW, different audio can be
recorded to separate tracks, and adjustments
can be made independently, allowing you to
easily create podcast materials. (See “Creating
podcasts (Windows only)” on page 21.)
NOTE
As before, only Mixing Driver In1/2 can be used
with mode presets other than Podcast Multi-
channel. When switching to or from a different
mode preset, the ASIO application must be
restarted and audio settings updated. The
Settings Panel must also be restarted.
