TASCAM MiNiSTUDIO PERSONAL
25
Specifications
Ratings
8
Sampling frequencies
44.1, 48, 88.2, 96 kHz
8
Quantization bit depth
16/24-bit
Analog audio input ratings
8
Mic input (balanced, IN 1)
Connector:
XLR-3-31 (1: GND, 2: HOT, 3: COLD)
6.3mm (1/4”) standard TRS stereo jack (Tip:
HOT, Ring: COLD, Sleeve: GND)
Input impedance: 2.4 kΩ
Nominal input level (VOLUME knob at MAX): −65
dBu (0.0004 Vrms)
Nominal input level (VOLUME knob at MIN): −20
dBu (0.0775 Vrms)
Gain range: 45 dB
8
Built-in mic (omnidirectional electret
condenser mic, IN 2)
Gain range: 45 dB
8
External mic inputs (can provide plug-in
power)
Connectors:
3.5mm (1/8”) 4-pole mini jack
3.5mm (1/8”) mini jack
Input impedance: 5 kΩ or more
Gain range: 45 dB
8
External input jack
Connector: 3.5mm (1/8”) stereo mini jack
Input impedance: 5 kΩ or more
Maximum input level: +7.7 dBV (2.427 Vrms)
Analog audio output ratings
8
Headphones outputs
Connectors:
Standard 6.3mm (1/4”) stereo jack
3.5mm (1/8”) 4-pole mini jack
3.5mm (1/8”) stereo mini jack
Maximum output: 15 mW + 15 mW or higher
(THD+N 0.1% or less, into 32Ω load)
Control input/output ratings
8
USB
Connector: 4-pin USB B-type
Transfer rate: USB 2.0 High Speed (480 Mbps)
8
DC IN 5V
Connector: USB Micro B type
Audio performance
8
Mic amp EIN (equivalent input noise)
−113 dBu or less
(150Ω termination, VOLUMEknob at MAX)
8
Frequency response
IN 1 w Headphones output*
At 44.1/48 kHz
20 Hz: 0 dB/−1 dB (headphones output, JEITA)
20 kHz: 0 dB/−3 dB (headphones output,
JEITA)
At 88.2/96 kHz
20 Hz: 0 dB/−1 dB (headphones output, JEITA)
40 kHz: 0 dB/−3 dB (headphones output,
JEITA)
8
S/N ratio
90 dB or higher (IN 1 w Headphones output*,
VOLUME knob at MIN, JEITA)
8
Distortion
0.008 % or less (IN 1 w Headphones output*,
1kHz sine wave, at nominal input level and
maximum output level, JEITA)
8
Crosstalk
95 dB or more (IN 1
w
Headphones output*,
1kHz sine wave, JEITA)
* (Standard 6.3mm (1/4”) stereo jack)
Operation requirements
Check the TEAC Global Site (http://teac-global.com/)
for the latest information about supported operating
systems.
Windows
8
Supported operating systems
Windows 10 32-bit
Windows 10 64-bit
Windows 8.1 32-bit
Windows 8.1 64-bit
Windows 7 32-bit SP1 or later
Windows 7 64-bit SP1 or later
(Windows 8, Windows Vista and Windows XP are
not supported)
8
Computer hardware requirements
Windows-compatible computer with a USB 2.0
port
8
CPU/processor speed
2 GHz or faster dual core processor (x86)
