20
TASCAM MiNiSTUDIO PERSONAL
8
EFFECT display area overview
1 EFFECT type switches
Use this to select a preset effect to apply to the
signals input through the inputs (1, 2, e and
r).
Options: RADIO, ECHO, MALE, FEMALE,
CHOPPER, OFF
2 ADJUST knob
Adjust the amount the sound is affected.
Turn it toward right increase the amount the
sound is affected.
8
PON trigger effect display area overview
1 Trigger sound status
Drag and drop audio files to load them.
i When a PON trigger pad (1/2/3) has an audio
file loaded, the name of that file is shown in the
trigger sound status area and it lights orange.
i When there is a problem with a loaded audio
file, the name of that file is shown in the trigger
sound status area but the area appears gray.
i When no audio file is loaded, the trigger sound
status area appears gray.
2 FADE IN knob
Sets the fade in time of the triggered sound.
Range: 0.00–5.0 s (default: 0.00 s)
3 LEVEL knob
Adjusts the volume of triggered sound.
Range: 0–100 (default: 60)
4 FADE OUT knob
Sets the fade out time of the triggered sound.
Range: 0.00–5.0 s (default: 0.00 s)
5 START TIME knob
Sets where playback of the triggered sound starts
in the file.
Range: 0.0–5.0 s (default: 0.0 s)
6 REPEAT button
When a repeat button is on, the arrows light
and the repeat function for the trigger sound is
enabled.
Default: off
7 LATCH/UNLATCH button
This sets the PON trigger pad mode.
LATCH: Press a PON trigger pad once to start
playback, and press it again to stop playback.
UNLATCH: Press and hold a PON trigger pad to
play the sound for as long as it is held down.
Release the button to stop playback.
8 VELOCITY button
This sets the operation modes of the PON trigger
pads (1/2/3).
When on, VELOCITY lights and operation is as
follows.
Default: off
On: The playback volume of the PON sound is
affected by how hard the PON trigger pad
(1/2/3) is pressed.
Off: The playback volume of the PON sound
is set by the LEVEL knob. It is not affected
by how hard the PON trigger pad (1/2/3)
is pressed.
Driver settings for specific purposes
(Windows only)
Purpose
ASIO driver set with
DAW software or
other application
Sound default
device
Using a DAW or other
application primarily
for recording
MiNiSTUDIO
US-32/42 ASIO*
Basic driver US-32*
Using a DAW or other
application primarily
for playback
MiNiSTUDIO
US-32/42 Mixing
Driver
MiNiSTUDIO
US-32/42
Using primarily for live
broadcast/karaoke
* This might improve performance depending on the
operating conditions.
NOTE
“Additional driver US-32/42” is compatible with
major communication apps.
