4. Screen.

5. <CARD STATUS> LED, indicating the activity of the Compact Flash card.

6. LEVEL sets the overall volume level of the active track. [FUNC] + LEVEL sets the main

output volume.

7. DATA ENTRY knobs. Used to set parameter values. Press the knob when turning to

change values in larger increments.

8. [TEMPO] key. Brings up the TEMPO menu. Tapping the BPM is done by holding

[FUNC] and then repeatedly tapping [TEMPO].

9. [SCENE A]/[SCENE B] + [TRIG] assigns one of 16 scenes to the A and B scene slots.

10. [PAGE] selects the active pattern page when GRID RECORDING mode is active.

Above the [PAGE] key four <PAGE> LEDs are found. The LEDs indicates what pattern

page that is currently played or edited. [FUNC] + [PAGE] opens the SCALE SETUP

menu where you can set track length and time signature.

11. The crossfader interpolates between the parameter values of scene A and scene B.

12. [STOP] key. Stops the playback of a pattern or arrangement. [FUNC] + [STOP] per-

forms a paste command.

13. [PLAY] key. Starts playback of a pattern or arrangement. Pressing [PLAY] a second

time pauses playback. [FUNC] + [PLAY] performs a clear command.

14. [RECORD] key. Toggles GRID RECORDING mode on/o. Starts LIVE RECORDING

mode if held while pressing [PLAY]. Pressing [FUNC] + [RECORD] performs a copy

command.

15. [TRACK PARAMETER] keys switches between the TRACK PARAMETER pages of the

active track. Pressing [FUNC] + a [TRACK PARAMETER] key or quickly double press-

ing a [TRACK PARAMETER] key will open the SETUP menu of the selected TRACK

PARAMETER page.

16. The [ARROW] keys. Used for menu navigation. They are called [UP], [DOWN], [LEFT]

and [RIGHT]. Pressing [LEFT]/[RIGHT] while no particular menu is open will tempo-

rarily nudge the BPM up or down.
