ELEKTRON Octatrack MKII [29/32] Technical information

7. TECHNICAL INFORMATION

ELECTRICAL SPECIFICATIONS

Impedance balanced audio outputs

Main outputs level: +17 dBu peak

Output impedance: 440 Ω unbalanced

Digital S/N ratio: 104 dB (20–20,000 Hz)

Headphones output

Headphones out level: +17 dBu peak

Output impedance: 55 Ω

Balanced audio inputs

Input level: +17 dBu peak

Audio input impedance: 21 kΩ

Digital S/N ratio: 106 dB (20–20,000 Hz)

Unit power consumption: 7 W typical

Compatible Elektron power supply: PSU-3b

HARDWARE

128 × 64 pixel OLED screen

MIDI In/Out/Thru

2 × 1/4” impedance balanced main audio

out jacks

2 × 1/4” impedance balanced cue audio

out jacks

4 × 1/4” balanced/unbalanced external input

jacks

1 × 1/4” stereo headphone jack

44,1 kHz, 24-bit D/A and A/D converters

Hi-speed USB 2.0 port

Power inlet: Center positive 5.5 × 2.5 mm

barrel jack, 12 V DC, 2 A

PHYSICAL SPECIFICATIONS

Sturdy steel casing

Dimensions: W 340 × D 184 × H 63 mm

(13.3” × 7.2” × 2.5”) (including knobs, jacks,

and rubber feet)

Weight: approximately 2.3 kg (5 lbs)

Maximum recommended ambient operating

temperature: +40˚C (+104˚F)
