![RME OCTAMIC XTC [60/62] Table commands](/views2/2007994/page60/bg3c.png)
60
User’s Guide OctaMic XTC © RME
24.3 Table
Commands
ID Command
Send Rec
0x10 request all parameters (incl. level data) x
0x11 request level data x
0x12
request changed parameters (in case of no changes: empty
block) x
0x20 set parameter (multiple parameters allowed) x
0x30 send parameters (multiple parameters possible) x
Parameters
Index Value
Send Rec Flag
0
Channel Settings Mic 1 (see Details below) x x s.d.
1
Channel Settings Mic 2 x x s.d.
2
Channel Settings Mic 3 x x s.d.
3
Channel Settings Mic 4 x x s.d.
4
Channel Settings Mic 5 x x s.d.
5
Channel Settings Mic 6 x x s.d.
6
Channel Settings Mic 7 x x s.d.
7
Channel Settings Mic 8 x x s.d.
8
Phones 1 Volume (see Details below) x x n.a.
9
Phones 1 Balance x x n.a.
10
Phones 1 Settings x x s.d.
11
Phones 2 Volume x x n.a.
12
Phones 2 Balance x x n.a.
13
Phones 2 Settings x x s.d.
14
Digital Routing ADAT Out, ADAT2 Out (see Details below) x x s.d.
15
Digital Routing AES Out x x s.d.
16
Digital Routing MADI 1-8, MADI 9-16 x x s.d.
17
Digital Routing MADI 17-24, MADI 25-32 x x s.d.
18
Digital Routing MADI 33-40, MADI 41-48 x x s.d.
19
Digital Routing MADI 49-56, MADI 57-64 x x s.d.
20
Digital Routing Rec. 9-16, Rec. 17-24 x x s.d.
21
Clock Settings x x
LSB
Bit 0-3: Clock Source (internal, WCK, AES1..AES4, ADAT,
MADI) 0x01
Bit 4: WCK always single 0x02
Bit 5: WCK termination active 0x04
MSB
Bit 0-3: Samplerate index (32k, 44.1k, 48k, 64k, 88.2k, 96k,
128k, 176.4k, 192k) 0x08
22
MADI Settings
LSB
Bit 0-1: Delay Compensation (0-Off, 1-Manual, 2-Auto-ID, 3-
Auto CA) x x 0x01
LSB Bit 2: MADI-Format (0: 56ch, 1: 64ch) x x 0x02
LSB Bit 3: MADI-Frame (0: 96k, 1: 48k) x x 0x04
MSB Bit 0-2: Delay Compensation ID (0-7 for ID 1-8) x x 0x08
