RME OCTAMIC XTC [61/62] Details
![RME OCTAMIC XTC [61/62] Details](/views2/2007994/page61/bg3d.png)
User’s Guide OctaMic XTC © RME
61
23
MIDI Source Select x x
LSB Bit 0-2: Source USB1 Output (see Value Table 2) 0x01
Bit 3-6: Source USB2 Output (see Value Table 2) 0x02
MSB Bit 0-2: Source DIN Output (see Value Table 2) 0x04
Bit 3-6: Source MIDI over MADI (see Value Table 2) 0x08
24
Group Enable x x
LSB Bit 0-3: Group 1..4 enable (ON) n.a.
MSB Bit 0-3: Group 1..4 AutoSet (AS) n.a.
25
Save/Load Preset (Receive only) x
LSB Load Preset 1..6, 0 for no operation n.a.
MSB Save Preset 1..6, 0 for no operation n.a.
25
Input State Lock/Sync (Send only at request of all params) x
LSB Lock: Bit 0: WCK, Bit 1-4: AES1-4, Bit 5: MADI, Bit 6: ADAT n.a.
MSB Sync: Bit 0: WCK, Bit 1-4: AES1-4, Bit 5: MADI, Bit 6: ADAT n.a.
26
Group Gain adjust x
LSB Delta Gain +64dB (0: -64dB, 64: 0dB, 127: +63dB) n.a.
MSB Group (1-4) n.a.
Level Meter data
26
Level Meter Mic 1 / 2 (see details below) x n.a.
27
Level Meter Mic 3 / 4 x n.a.
28
Level Meter Mic 5 / 6 x n.a.
29
Level Meter Mic 7 / 8 x n.a.
30
Level Meter Phones 1 x n.a.
31
Level Meter Phones 2 x n.a.
Details
Channel Settings Mic
Flag
LSB Bit 0-5 Gain (0: 0dB, 1: 10dB...56:65dB) 0x01
Bit 6: Phase Invert 0x02
MSB Bit 0: Mute 0x04
Bit 1: AutoSet 0x08
Bit 2: +48V 0x10
Bit 3: Pad (Channel 1-4)/Instrument (Channel 5-8) 0x20
Bit 4-6: Group (0: off, 1..4: group) 0x40
Digital Routing
LSB Bit 0-3: Source 1 (see Value Table 2) 0x01
MSB Bit 0-3: Source 2 (see Value Table 2) 0x02
Phones Volume
LSB Bit 0-3: 1/10 dB of Volume[dB]+65.0 n.a.
MSB integer part of Volume[dB]+65.0 (0...71 for -65...+6dB)
Phones Balance
LSB 1/100 Balance n.a.
MSB Bit 0: Left (1) / Right (0)
