User’s Guide OctaMic XTC © RME
9
4.2 Quick Start
After connection of all cables and power-on of the device, the configuration of the OctaMic XTC
starts in the menu SETUP – Options - Clock. Choose a clock source and a sample rate.
The next step is the GAIN setting. Press the desired SELECT button and adjust the gain with
the encoders, so that the two level meters do not show overload.
The digital output to send out the converted analog signal is defined in SETUP – Options – Digi-
tal Routing. Press encoder 2 to navigate downwards through the list, for example to ADAT Out.
By turning encoder 2 the signal source of the ADAT output can be set to Mic 1-8 (default).
The OctaMic XTC stores all settings before switching off, and sets them automatically when
switching on the next time. The storing process is triggered 5 seconds after the last change.
5. Accessories
RME offers several optional components for the OctaMic XTC:
Part Number Description
OK0050 Optical cable, Toslink, 0.5 m (1.7 ft)
OK0100 Optical cable, Toslink, 1 m (3.3 ft)
OK0200 Optical cable, Toslink, 2 m (6.6 ft)
OK0300 Optical cable, Toslink, 3 m (9.9 ft)
OK0500 Optical cable, Toslink, 5 m 16.4 ft)
OK1000 Optical cable, Toslink, 10 m (32.8 ft)
BO25MXLR4M4F1PRO Digital Breakout Cable Pro, AES/EBU
25-pin D-sub to 4 x XLR male + 4 x XLR female, 1m (3.3 ft)
BO25MXLR4M4F3PRO same, 3 m (9.9 ft)
BO25MXLR4M4F6PRO same, 6 m (19.8 ft)
BO25M25M1PRO Digital D-sub cable Pro, AES/EBU
25-pin D-sub to 25-pin D-sub, 1m (3.3 ft)
BO25M25M3PRO same, 3m (9.9 ft)
BO25M25M6PRO same, 6m (19.8 ft)
BOB32 BOB-32, Universal breakout box, 19" 1 Unit height. The professional
digital AES/EBU breakout solution
