RME OCTAMIC XTC [62/62] Abbreviations
![RME OCTAMIC XTC [62/62] Abbreviations](/views2/2007994/page62/bg3e.png)
62
User’s Guide OctaMic XTC © RME
Phones Settings
LSB Source Bit 0..6 0x01
MSB Bit 0: Bit 7 Source (see Value Table 1)
Bit 1: Mute 0x02
Bit 2-3: Phase Invert (0: off, 1: both, 2: left, 3: right) 0x04
Bit 4: Level (0: Low, 1: High) 0x08
Level Meter (Send only)
LSB Channel 1
MSB Channel 2
Value 126: OVR
125..95: 0dB..-6dB (p[dB] = (Value – 125) * 0.2)
94...23: -6.5dB..-42dB (p[dB] = (Value – 107) * 0.5)
22..1: -43..-64dB (p[dB] = Value – 65)
0: underflow
Abbreviations
n.a. not assigned
s.d. see details
Value Table 1 – Phones Sources
0 1 2 3 4 5 6 7
0.. Play 1/2 Play 3/4 Mic 1 Mic 2 Mic 3 Mic 4 Mic 5 Mic 6
8.. Mic 7 Mic 8 Mic 1/2 Mic 3/4 Mic 5/6 Mic 7/8 Mic 1-8 Mic 1-8S
16.. ADAT 1 ADAT 2 ADAT 3 ADAT 4 ADAT 5 ADAT 6 ADAT 7 ADAT 8
24.. ADAT 1/2 ADAT 3/4 ADAT 5/6 ADAT 7/8 AES 1 AES 2 AES 3 AES 4
32.. AES 5 AES 6 AES 7 AES 8 AES 1/2 AES 3/4 AES 5/6 AES 7/8
40.. MADI 1 MADI 2 MADI 3 MADI 4 MADI 5 MADI 6 MADI 7 MADI 8
48.. MADI 1/2 MADI 3/4 MADI 5/6 MADI 7/8 MADI 9 MADI 10 MADI 11 MADI 12
56.. MADI 13 MADI 14 MADI 15 MADI 16 MADI 9/10 MA 11/12 MA 13/14 MA 15/16
64.. MADI 17 MADI 18 MADI 19 MADI 20 MADI 21 MADI 22 MADI 23 MADI 24
72.. MA 17/18 MA 19/20 MA 21/22 MA 23/24 MADI 25 MADI 26 MADI 27 MADI 28
80.. MADI 29 MADI 30 MADI 31 MADI 32 MA 25/26 MA 27/28 MA 29/30 MA 31/32
88.. MADI 33 MADI 34 MADI 35 MADI 36 MADI 37 MADI 38 MADI 39 MADI 40
96.. MA 33/34 MA 35/36 MA 37/38 MA 39/40 MADI 41 MADI 42 MADI 43 MADI 44
104.. MADI 45 MADI 46 MADI 47 MADI 48 MA 41/42 MA 43/44 MA 45/46 MA 47/48
112.. MADI 49 MADI 50 MADI 51 MADI 52 MADI 53 MADI 54 MADI 55 MADI 56
120.. MA 49/50 MA 51/52 MA 53/54 MA 55/56 MADI 57 MADI 58 MADI 59 MADI 60
128.. MADI 61 MADI 62 MADI 63 MADI 64 MA 57/58 MA 59/60 MA 61/62 MA 63/64
Value Table 2 – Digital Routing Sources
0 1 2 3 4 5 6 7
0.. Mic 1-8 ADAT IN AES IN M 1-8 M 9-16 M 17-24 M 25-32 M 33-40
8.. M 41-48 M 49-56 M 57-64 PB 1-8 PB 5-12 PB 9-16 PB13-20 PB17-24
Value Table 3 – MIDI Sources
0 1 2 3 4 5
OFF USB1 USB2 MADI In DIN in Control
