Overview

1•6

Speaker Outputs - HD100

16 Ohm Out – If you’re using one 16 Ohm cab, a 4x12 for example, connect

it to the single A Speaker Output.

8 Ohm Out – Use the two B Speaker Outputs to drive two 16 Ohm cabs, or

plug into one of the B outputs to drive a single 8 Ohm cab.

4 Ohm Out – If you’re using two 8 Ohm cabs, plug them into the two C

Speaker Output jacks; if using a single 4 Ohm cab, plug it into one of the C outputs.

Speaker Outputs - 112 / 212

8 Ohm Out – If you’re using one 8 Ohm cab, connect it to the single A Speaker

Output.

4 Ohm Out – If you’re using two 8 Ohm cabs, plug them into the two B

Speaker Output jacks; if using a single 4 Ohm cab, plug it into one of the B outputs.
