Overview

1•4

Hold Tap For Tuner – To enter Tuner mode, hold the Tap button for a few seconds.

The Tuner will appear in the LCD Display, along with each note you’re tuning. It will

indicate whether you’re sharp or ﬂat via the graphic lines to the right or left, respectively.

When you’re in tune, the graphic ** symbols will be lined up in the center of the LCD.

Reverb – When you adjust the Reverb knob, a bar graph will display the Reverb

Mix level for a few seconds in the LCD, along with the current Reverb Model name,

either Lux Spring or Vintage Plate. To toggle between the two Reverb Models, turn the

Presets knob left or right while the bar graph is displayed.

Quick Loop – Pressing this button puts you in Looper Control Mode. When

it’s lit, the Tap button becomes your one-button control for Recording, Overdubbing, loop

Playback and Stop. *See Chapter 5 for in-depth info on recording and playing loops.

4-way Navigation Disc – Press the Up, Down, Left, or Right arrows to

select a parameter that you’d like to change. The arrows are displayed in the LCD for each

function. *For in-depth info on the many Amp Model and FX parameters you can access

with this control, see Chapter 3 Editing.

Presets/Press To Edit – When in Preset Select Mode, turn this knob to

scroll thru 32 banks of presets. Push in the Presets knob to enter Edit Mode. This enables

you to set various parameters for all your FX, as well as select settings in Setup Mode and

perform other functions. *See Chapter 3 for more info.

LCD Display – The LCD (liquid crystal display) is your window into the

power of the Spider Valve MkII. Here you’ll see various “pages” as you adjust the various

controls, including Momentary Tone Display, Momentary FX Display, and numerous other

Parameter menus as you ﬁne-tune your guitar sounds. The LCD is designed to give you

instant feedback on any parameter you’re currently adjusting.

Presence – This is a Presence control for the tube power amp. It works even if

you plug a POD X3 into the power amp, for example, using the Power Amp In jack.

Master Volume – Sets the Master output level of your Spider Valve MkII

power amp. This also controls the level of the Direct Output in Performance Mode.

Standby Switch – This switch puts the amp in standby mode when desired.

Power Switch – Flick this switch to power up your Spider Valve MkII.
