Appendix A: MIDI
A•6
Preset Select
Spider Valve Mk II User Presets are comprised of 32 Banks of A B C D Channels.
To call up a particular User Preset, insert a Program Change value of 0-127. *0 would be
Preset 1A, 1 would be 1B, 4 would be 2A, 5 would be 2B, and so on, up to 127 for 32D.
PRESET SELECT
Bank MSB Bank LSB Program Range Program Bank Program Number
0 0 0-127 User Presets *1A-32D
0 1 0-15 Amp Models
