LINE 6 Spider Valve MkII HD100 [12/41] Saving
![LINE 6 Spider Valve MkII 112 [12/41] Saving](/views2/2009078/page12/bgc.png)
Presets
2•2
Saving
Once you’ve edited a preset to your liking, you’ll want to save it in one of the User Banks.
Here’s an overview of the Save routines for Spider Valve MkII:
• L/R Arrows on
4-way Nav Disc
select one of the
14 characters of
the Preset name
[it will flash]
• Up/Down
Arrows select
the next/previous
User Bank as the
Save destination
• Turn Presets
knob to change
the current
character in
Preset name
[push for quick
change of type]
• Current Preset
Save destination
[Bank 31 Chan A]
To save a preset:
• Press & hold the channel button of the current preset location - all 4 LEDs will flash
• Select the destination Bank by pressing the up/down arrows on the Nav Disc
• Rename the preset if desired - L/R arrows select character - Presets knob changes it
• Once your preset name is set, press a Channel button as your preset destination
• The LEDs will flash rapidly a few times indicating the Save is complete
• Your preset is now saved to the Bank and Channel location you’ve selected
