The Haze button allows an instant on/off switching in the Manual mode, so that the

haze output setting need not be reduced to zero in order to switch the effect off.

Cycled Feature Explanation.

HAZE Volume of Haze vapour produced

PROJ Output power of fans effecting projection distance

DIR Relative power of fans effecting angle of projected haze

SWP Speed of automatic direction variation, sweeping the

output of haze. This overrides the Direction setting, and

can be set to “Off”. If the sweep is on, then the setting of

the Direction angle will have the following effect.

0 degrees - sweep will be from 0 to 45 degrees.

45 degrees - sweep will be a full 0 to 90 degrees.

90 degrees - sweep will be from 45 to 90 degrees.

DMX Allows the first DMX channel in the sequence of four

to be set. This will be the Haze output

USE2, USE3, USE4 allows the channels following the set DMX channel to be used

(ON) or rejected (OFF). If a channel is set as OFF then the manual set value will be

used. This allows the user to make full use of a restricted amount of DMX channels

if enough channels are not available on a control unit. It also allows simplified DMX

control if the full range of MVS features do not need to be varied.

In the DMX mode, the upper Led ( Store / DMX status) will indicate if a correct

dmx signal is being received. If the selection on the display is set to Haze, Projection,

Direction or Sweep, then DOFF will also appear if the dmx signal is not correct.

The main display will show the variation in value as the dmx signal is varied for the

selected feature. Note – Once DMX is selected, the SELECT buttons are inhibited,

so in order to display the DMX variations, the required feature (Haze, Projection

etc) should be active before selecting the DMX mode. Simply switch back to manual

mode and select another feature to display its DMX variation, then switch the DMX

on again.

Normally there should be no need to ‘prime’ fluid into the system. If there are

pockets of air and fluid in the pipe, these will be removed as the pump is activated

during normal haze output. It might take a few minutes to completely free the air

pockets, but no harm is caused during this process. Should it be felt necessary to

prime the system quickly, then this can be done by switching to DMX control
