without an actual dmx connection input, and pressing the Select and Haze buttons

at the same time. To stop priming, just release the buttons.

Note – Too much fluid in the system might force hot fluid from the output nozzle –

do not over prime! If this is the case then tilt and position the machine such that this

excess fluid can be expelled safely.

When the machine is switched on, it will perform a single cleaning process routine.

This will last approximately 2 minutes. This is a very short time compared to

alternative systems which have to heat a standard type heat exchanger. After this

operation the machine will be ready to operate. Initial Haze output might take a

short while to reach a steady state due to the fact that the cleaning process will have

cleared to fluid supply line. After this initial settling state, operation will be

immediate.

Manual Operation

When the machine has performed the initial cleaning routine, it will be ready to

operate. Pressing the Manual button will make operation available via the control

panel.

By pressing the Select button each of the features can be adjusted to suit the

operating requirements. Use the Up / Down buttons to adjust.

Haze output. Set how much haze volume is required

Projection Set how far the haze will be fanned

Direction At what angle is the projection required

Sweep Speed of automatic sweeping haze or fixed angle (Off)

( Note.. if Sweep is on, then Angle 0 degrees = 0 to 45 sweep, Angle 45 degrees = 0 to

90 sweep, Angle 90 degrees= 45 to 90 sweep )

The DMX channel assignment and channel options are irrelevant in Manual mode.

All that is required now is the use of the Haze button. Press for On, Press again for

Off.

If the settings are required to set as defaults in memory, then at each final

adjustment press the Manual and Store keys at the same time. When the machine is

switched on again, these settings will be restored.

DMX Operation

Before using DMX set the required first channel (Haze volume) by selecting Manual

mode, then use the Select button to select the DMX feature. Press the Up or Down

button (hold down to auto increment or auto decrement, the longer held the faster

the change) to reach the desired channel. The next 3 channels are automatically

assigned to Projection, Direction and Sweep. If their use (or individual use) is not

required then select Use2,3,4 and choose Yes or No to use or ignore. If a channel is
