TUF Z390M-PRO GAMING specications summary
(continued on the next page)
Storage
Intel
®
Z390 Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage
Technology support
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280/22110 storage
devices support (both PCIE x4 & SATA modes)**
- 1 x M.2_2 Socket 3 with M Key, type 2242/2260/2280 storage devices
support (PCIe x4 mode)
- 6 x SATA 6Gb/s ports
- Intel
®
Optane™ Memory Ready
* Hyper M.2 X16 series card is sold separately. Install a Hyper M.2 X16 series card
and enable this card under BIOS settings.
** The M.2_1 socket shares SATA_2 port when using an M.2 SATA mode device.
Adjust BIOS settings to use a SATA device.
LAN
Intel
®
I219V Dual interconnect between the integrated Media Access
Controller (MAC) and Physical Layer (PHY)
TUF LANGuard
ASUS Turbo LAN Utility
Audio
Realtek
®
S1200A 8-Channel* High Denition Audio CODEC
- DTS Custom for TUF GAMING Headphone
- Audio Shielding: Ensures precision analog/digital separation and greatly
reduces multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right channels to
guard the quality of the sensitive audio signals
- Premium Japanese audio capacitors: Provide warm, natural and immersive
sound with exceptional clarity and delity
- Supports jack-detection and front panel jack-retasking
* Choose the chassis with HD audio module in front panel to support 8-channel
audio output.
USB
Intel
®
Z390 Chipset:
- 2 x USB 3.1 Gen 2 (up to 10Gbps) ports
(1 port at mid-board; 1 port at back panel, [teal blue], Type A)
- 7 x USB 3.1 Gen 1 ports
(2 ports at mid-board; 4 ports at back panel, [blue], Type A; 1 port at
back panel, Type C)
- 4 x USB 2.0 ports ( 4 ports at mid-board)
Back I/O Ports
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x HDMI port
1 x DisplayPort
1 x USB3.1 Gen 2 (up to 10Gbps) port (Type A [teal blue])
1 x USB3.1 Gen 1 port (Type C)
4 x USB3.1 Gen 1 ports (Type A [blue])
1 x LAN (RJ45) port
3 x Audio jacks
