Asus TUF Z390M-PRO GAMING [66/86] Advanced menu

3-16

Chapter 3: BIOS Setup

Chapter 3

3.6.3 System Agent (SA) Conguration

The items in this menu allow you to adjust the Link Speed for PEG Port and Multi-Monitor.

3.6 Advanced menu

The Advanced menu items allow you to change the settings for the CPU and other system

devices.

Be cautious when changing the settings of the Advanced menu items. Incorrect eld values

can cause the system to malfunction.

3.6.1 Platform Misc Conguration

The items in this menu allow you to change the ASPM for PCH and SA PCI Express.

3.6.2 CPU Conguration

The items in this menu show the CPU-related information that the BIOS automatically

detects.

The items in this menu may vary based on the CPU installed.

CPU - Power Management Control

This item allows you to manage and congure the CPU’s power.

Intel(R) SpeedStep(tm)

This item allows more than two frequency to be supported.

Conguration options: [Auto] [Disabled] [Enabled]

Intel(R) Speed Shift Technology

This item allows you to enable or disable the Intel(R) Speed Shift Technology support.

When enabled, CPPC v2 interface allows hardware controlled P-states.

Conguration options: [Auto] [Disabled] [Enabled]

Turbo Mode

This item allows you to automatically set the CPU cores to run faster than the base

operating frequency when it is below the operating power, current and temperature

specication limit.

Conguration options: [Enabled] [Disabled]

CPU C states

This item allows you to set the power saving of the CPU states.

Conguration options: [Auto] [Disabled] [Enabled]

CFG Lock

This item allows you to congure MSR 0xE2[15], CFG lock bit. Conguration options:

[Disabled] [Enabled]
