Asus TUF Z390M-PRO GAMING [22/86] Chapter 1

1-8

Chapter 1: Product Introduction

Chapter 1

• InsingleVGAcardmode,usethePCIEX16_1slot(gray)foraPCIExpressx16

graphicscardtogetbetterperformance.

• WerecommendthatyouprovidesufcientpowerwhenrunningCrossFireX™orSLI™

mode.

• ConnectachassisfantothemotherboardconnectorlabeledCHA_FAN1-2when

usingmultiplegraphicscardsforbetterthermalenvironment.

• HyperM.2X16cardispurchasedseparately.

• EnabletheHyperM.2X16cardunderBIOSsettings.

Hyper M.2 X16 card

conguration

PCI Express 3.0 operating mode

PCIEX16_1 PCIEX16_2

2Intel

SSDonCPUsupport x8 x4+x4

3Intel

SSDonCPUsupport x8+x4+x4 N/A

VGA Conguration

PCIe operating mode

PCIEX16_1 PCIEX16_2

SingleVGA/PCIecard

x16

(singleVGArecommended)

N/A

DualVGA/PCIecards x8 x8
