ASUS TUF Z390M-PRO GAMING
1-15
Chapter 1
6. CPU, CPU optional, and chassis fan connectors; AIO pump connector (4-pin
CPU_FAN; 4-pin CPU_OPT; 4-pin CHA_FAN1-2; 4-pin AIO_PUMP)
Connectthefancablestothefanconnectorsonthemotherboard,ensuringthatthe
blackwireofeachcablematchesthegroundpinoftheconnector.
• DONOTforgettoconnectthefancablestothefanconnectors.Insufcientairow
insidethesystemmaydamagethemotherboardcomponents.Thesearenotjumpers!
Donotplacejumpercapsonthefanconnectors!
• EnsurethattheCPUfancableissecurelyinstalledtotheCPUfanconnector.
• Connectthepumpcablefromtheall-in-onecooler(AIOcooler)totheAIO_PUMP
header,andconnectthefancablestotheCPU_FANand/orCPU_OPTheader(s).
• IfyourAIOcoolerhasmorethanonefan,youmayneedtouseapigtailcableto
connectthecoolertothemotherboard.
• Ensuretofullyinsertthefancabletothefanconnector.
7. Serial port connector (10-1 pin COM)
Thisconnectorisforaserial(COM)port.Connecttheserialportmodulecabletothis
connector,theninstallthemoduletoaslotopeningatthebackofthesystemchassis.
TheCOMmoduleispurchasedseparately.
CHA FAN PWM
CHA FAN IN
CHA FAN PWR
GND
GND
CHA FAN PWR
CHA FAN IN
CHA FAN PWM
®
TUF Z390M-PRO GAMING Fan connectors
A
C
E
D
B
CPU_FAN
CPU FAN PWM
CPU FAN IN
CPU FAN PWR
GND
CPU_OPT
CPU FAN PWM
CPU FAN IN
CPU FAN PWR
GND
AIO_PUMP
AIO PUMP PWM
AIO PUMP IN
AIO PUMP PWR
GND
A B
C
CHA_FAN1
CHA_FAN2
D E
®
TUF Z390M-PRO GAMING Serial port connector
COM
PIN 1
DCD1
TXD1
GND
RTS1#
PI1#
RXD1
DTR1
DSR1
CTS1
