Asus TUF Z390M-PRO GAMING [33/86] Chapter 1

ASUS TUF Z390M-PRO GAMING

1-19

Chapter 1

12. RGB headers (4-pin RGB_HEADER1/2)

TheseheadersareforRGBLEDstrips.

TheRGBheaderssupport5050RGBmulti-colorLEDstrips(12V/G/R/B),withamaximum

powerratingof3A(12V),andnolongerthan3m.

Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyisswitched

offorthepowercordisdetachedfromthepowersupply.Failuretodosomaycausesevere

damagetothemotherboard,peripherals,orcomponents.

• ActuallightingandcolorwillvarywithLEDstrip.

• IfyourLEDstripdoesnotlightup,checkiftheRGBLEDextensioncableandthe

RGBLEDstripisconnectedinthecorrectorientation,andthe12Vconnectoris

alignedwiththe12Vheaderonthemotherboard.

• TheLEDstripwillonlylightupwhenthesystemisoperating.

• TheLEDstripispurchasedseparately.

PIN 1

+12V G

RGB_HEADER1

TUF Z390M-PRO GAMING RGB_HEADER connectors

PIN 1

+12V G

RGB_HEADER2
