Asus TUF Z390M-PRO GAMING [68/86] Chapter 3

3-18

Chapter 3: BIOS Setup

Chapter 3

3.6.7 Onboard Devices Conguration

The items in this menu allow you to switch between PCIe Lanes and congure onboard

devices.

Hyper M.2X16 [Enabled][Disabled]

[Disabled] Only one SSD installed onto the Hyper M.2 X16 card can be detected.

[Enabled] Two or three SSDs installed onto the Hyper M.2 X16 card can be detected.

The number of SSDs that can be detected varies with the congurations of the PCIe X16

slots.

HD Audio

This item allows you to use the Azalia High Denition Audio Controller.

Conguration options: [Disabled] [Enabled]

Intel LAN Controller

This item allows you to enable or disable the Intel LAN controllers.

Conguration options: [Disabled] [Enabled]

LED lighting

When system is in working state

This item allows you to turn the RGB LED lighting on or off when the system is in the

working state.

Conguration options: [On] [Off]

When system is in sleep, hibernate or soft off states

This item allows you to turn the RGB LED lighting on or off when the system is in the

sleep, hibernate or soft off states.

Conguration options: [On] [Off]

3.6.8 APM Conguration

The items in this menu allow you to set system wake and sleep settings.

ErP Ready

This item allows you to switch off some power at S4+S5 or S5 to get the system ready for

ErP requirement. When set to [Enabled], all other PME options are switched off.

Conguration options: [Disabled] [Enable(S4+S5)] [Enable(S5)]

3.6.9 PCI Subsystem Settings

SR-IOV Support

This option enables or disables Single Root IO Virtualization Support if the system has

SRIOV capable PCIe devices.

Conguration options: [Disabled] [Enabled]

3.6.6 PCH-FW Conguration

This item allows you to congure the rmware TPM.
