Asus TUF Z390M-PRO GAMING [47/86] Chapter 2

ASUS TUF Z390M-PRO GAMING

2-13

Chapter 2

* LAN ports LED indications

SPEED

LED

ACT/LINK

LED

LAN port

Activity Link LED Speed LED

Status Description Status Description

OFF No link OFF 10 Mbps connection

ORANGE Linked ORANGE 100 Mbps connection

BLINKING Data activity GREEN 1 Gbps connection

You can disable the LAN controllers in BIOS. Due to hardware design, the LAN port’s LEDs

may continue to blink even when disabled.

Port

Headset

2-channel

4-channel 6-channel 8-channel

Light Blue (Rear

panel)

Line In Rear Speaker Out

Rear Speaker

Out

Rear Speaker

Out

Lime (Rear panel) Line Out

Front Speaker

Out

Front Speaker

Out

Front Speaker

Out

Pink (Rear panel) Mic In Mic In Bass/Center Bass/Center

Lime (Front panel) - - - Side Speaker Out

** Audio 2, 4, 6 or 8-channel conguration

For a 7.1-channel speaker setup, refer to the 7.1-channel conguration in the table.
