70
UPPER/LEFT temperature zone and press the
right side UP and DOWN keys to control the
internal temperature of the LOWER/RIGHT
temperature zone. When you press the two
keys at the first time, the display will show the
last temperature set previously.
IMPORTANT: The temperature set for the
LOWER temperature zone must always be
higher than that in the UPPER temperature
zone. For optimal performance, the set
temperature of the two zones should differ by at
least 4°C.
The temperature that you desire to set will
increase 1ºC or 1ºF if you press the UP mark
once, on the contrary the temperature will
decrease 1ºC or 1ºF if you press the DOWN
mark once. The display flashes while you make
the setting.
After the temperature has been set, the display
shows the current inner temperature of the
particular temperature zone.
To view the set temperature at any time, press
the UP or DOWN key, the set temperature will
temporarily flash in the display for 5 seconds.
Then the display shows the current inner
temperature again.
USE AND CONTROL – THREE ZONE
The Controls of Your Unit
Upper Control Unit
Lower Control Unit
POWER
To turn the appliance on/off, press and hold the
key for 5 seconds until themperature display lights
up or goes out.
NOTE: Pressing the key once can switch off the
audible alarm when the alarm is on.
LIGHT
Used to turn the inner light on/off.
UP
Used to increase (warm) the set temperature by 1°C
or 1ºF.
DOWN
Used to decrease (cool) the set temperature by 1°C
or 1ºF.
Display
Display the digital temperature and service
indicators. is for UPPER temperature zone, is
for MIDDLE temperature zone and is for LOWER
temperature zone.
Indicator Light
The indicator light is located at the right lower corner
of the display. The indicator light will be on when the
multi-key function is selected. To perform the multi-
key function, press and hold the first key, then press
the rest key for at least 5 seconds and then release
all the keys.
ºF/ºC Selector
Select the temperature display setting in Fahrenheit
or Celsius degree. To change the temperature from
Fahrenheit to Celsius or from Celsius to Fahrenheit,
press and hold the LIGHT key for 5 seconds.
Setting the Temperature Control
The unit has three temperature zones. The
temperature of all zones can be set separately.
The temperature settings of UPPER
temperature zone are adjustable with the range
+11º to +22ºC (52º-72ºF). The preset
temperature at the factory is +18ºC (65ºF).
The temperature settings of MIDDLE
temperature zone are adjustable with the range
+5º to +11ºC (41º-52ºF). The preset
temperature at the factory is +8ºC (46ºF).
The temperature settings of LOWER
temperature zone are adjustable with the range
+11º to +13ºC (52º-56ºF). The preset
temperature at the factory is +12ºC (54ºF).
Temperature control for UPPER and MIDDLE
temperature zones is at upper control unit.
Temperature control for LOWER temperature
zone is at lower control unit.
When you press the two keys at the first time,
the display will show the last temperature set
previously. The temperature will increase 1°C or
1ºF if you press the UP key once, on the
contrary the temperature will decrease 1°C or
1ºF if you press the DOWN key once. The
display flashes while you make the setting.
After the temperature has been set, the display
shows the current inner temperature of the
particular temperature zone.
To view the set temperature at any time, press
the UP or DOWN key, the set temperature will
temporarily flash in the display for 5 seconds.
Then the display shows the current inner
temperature again.
