76
USE AND CONTROL (DAU-32.81B, DAU-
32.81SS, DAU-32.81DB, DAU-32.81DSS,
DX-51.15DBK/DP, DX-51.150DSK/DP)
SINGLE ZONE
DUAL ZONE
POWER
To turn ON/OFF the appliance, press the button
and hold 2 seconds.
SETTING THE TEMPERATURE
Model: DAU-32.81B, DAU-32.81SS – Single zone -
If you desire to change the temperature, set the
temperature as you desire by touching the or
button. The temperature that you desire to set
will increase 1ºC if you touch the button once; on
the contrary the temperature will decrease 1ºC if you
touch the button once.
Model: DAU-32.81DB, DAU-32.81DSS, DX-
51.150DSK/DP, DX-51.150DSK/DP – Dual zone
The temperature range of lower zone is +12ºC to
+22ºC which is suitable for storing white and red
wines. The temperature range of upper zone is +5ºC
to +12ºC which is suitable for storing sparkling and
white wines.
If you desire to change the temperature, set the
temperature as you desire by touching the
button. Temperature will increase or decrease by
1ºC when you touch the button.
LOCK
When the appliance is power on, all the buttons are
on unlock position. If there’s no any operation in 3
minutes, all the buttons will be in lock position. Press
button for 2 seconds, all the button will be lock
or unlock.
LIGHT
Press the button to turn the light ON/OFF.
The button of light has the function of auto off or
manual off.
a.Holds the light button till you hear two beep sound,
light will turn off after 10 minutes automatically.
b.Holds the light button till you hear three beep
sound, light will be turn off manually.
GENERAL INFORMATION
Operating Noises
The unit is cooled by a compressor (refrigeration
aggregate). The compressor pumps coolant through
the cooling system, producing operating noise. Even
when the compressor cuts out, noises caused by
changes in temperature and pressure are
unavoidable. Operating noise will be most audible
immediately after the compressor cuts in. It
becomes quieter as the operating period continues.
The following noises are normal and occur from time
to time:
- Gurgling sound, caused by the refrigerant flowing
through the appliance’s coils,
- Humming noise made by the motor compressor.
This noise can get louder for brief periods when
the motor is switching on.
- Cracking/popping sounds, resulting from the
materials contraction and expansion due to
temperature variations,
- Fan operating sound, to circulate the air within the
wine cabinet.
Unusual noise is normally the result of improper
installation. Under no circumstances must tubing
come into contact with a wall, other furniture or with
other tubing.
Where the unit is installed in open-plan kitchen or in
partition walls, the level of operating noise will be
heard more acutely. However, this is due to the
surrounding architecture and not to the unit.
An individual’s perception of noise is directly linked
to the environment in which the unit is located, as
well the specific type of models. Our appliances are
in line with international standards for such
appliance and in line with the latest technical
developments. But please remember that the noise
of the compressor and the coolant circulating in the
system is unavoidable.
DEFROSTING / HYGROMETRY /
VENTILATION
Your unit is designed with an automatic defrost
system. During the “Off-cycle” the evaporator behind
the rear wall of the unit defrosts automatically. The
condensate collects in the drain trough behind the
rear wall of the unit, and part of it flows through the
drainage hole into the drip tray by/above the
compressor. The heat is transferred from the
discharge pipe or compressor and evaporates any
condensation that has collected in the tray. Part of
the remaining water is collected within the unit for
