Note:
For the first time to use the appliance or to restart
the appliance after having been shut off for a long
time, you may find a few degrees variance between
the set temperature and the displayed temperature.
It will be normal after a few hours running.
WARNING!
Middle zone set temperature must be at least 5º
C lower than upper and lower zone set
temperature mut be higher than upper zone
SELECTING FAHRENHEIT(ºF) & CELSIUS
(ºC) DISPLAY
For Single Zone
Touch the marks with 2 fingers at the same
time and hold for 5 seconds, you can interchange
the Fahrenheit and Celsius display.
For Dual Zone
Directly touch the mark , you can interchange the
Fahrenheit and Celsius display for both zones at the
same time.
For Triple Zone
The ºC / ºF shifting of upper zone is same as Single
Zone above. The ºC / ºF shifting of Mid Zone and
Lower Zone is same as Dual Zone above.
SILENT MODE
The appliance can be set to Silent Mode, which will
slow down the fans speed when the inside
temperature reaches the temperature set.
The Silent Mode is set as "ON" by default, to turn off
it, when the control panel is under locked condition,
press and hold the light mark for 3 seconds, the
icon ºC or ºF will stay on to indicate the Silent Mode
is off.
To turn on Silent Mode again, when the control panel
is under locked condition, press and hold the light
mark for 3 seconds, the icon ºC or ºF will flash
every 2 seconds continuously to indicate the Silent
Mode is working.
FUNCTION INDICATING LIGHT
For Single Zone
When indicator is on, compressor works.
For Dual Zone
The Indicator 1 will flash every 2 seconds when the
unit is plugged in.
The Indicator 1 will stay on when the compressor
starts to work.
The Indicator 2 will flash every 3 seconds when the
heating function of lower zone starts to work.
The Indicator 2 will stay on when the cooling.
function of lower zone starts to work.
USE AND CONTROL (DAB-42.117DB, DAB-
42.117DSS, DAB-48.125B, DAB-48.125SS,
DAU-32.78, DAU-46.146, DAU-52.146B,
DAU-52.146SS)
SINGLE ZONE
LIGHT
Control the interior light ON/OFF
RUN
When it’s ON, the cooling system runs.
POWER
Control this appliance turn on/off. (press and hold
this button for approximately 3 seconds);
“UP” BUTTON
Press once the “UP” button, the temperature will
raise 1ºC.
