16 | English
Technical Data
Hand-held circular saw GKS 600
Article number
3601FA90..
Rated power input W 1200
No-load speed min
-1
5200
Max. cutting depth with 165mm saw blade diameter
– at a 0° mitre/bevel angle mm 55
– at a 45° mitre/bevel angle mm 37
Spindle lock ●
Base plate dimensions mm 235 x 138
Max. saw blade diameter mm 165
Min. saw blade diameter mm 160
Max. base blade thickness mm 2.2
Locating bore mm 20
Weight according to
EPTA-Procedure 01:2014
kg 3.6
Protection class
/ II
The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.
Noise/vibration information
Noise emission values determined according to
EN62841-2-5.
Typically, the A-weighted noise level of the power tool is:
Sound pressure level 91dB(A); sound power level
102dB(A). Uncertainty K=3dB.
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN62841-2-5:
Sawing wood: a
h
=1.6m/s
2
, K=1.5m/s
2
The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure and may be used to com-
pare power tools. They may also be used for a preliminary
estimation of vibration and noise emissions.
The stated vibration level and noise emission value repres-
ent the main applications of the power tool. However, if the
power tool is used for other applications, with different ap-
plication tools or is poorly maintained, the vibration level
and noise emission value may differ. This may significantly
increase the vibration and noise emissions over the total
working period.
To estimate vibration and noise emissions accurately, the
times when the tool is switched off or when it is running but
not actually being used should also be taken into account.
This may significantly reduce vibration and noise emissions
over the total working period.
Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and application tools, keeping their hands warm,
and organising workflows correctly.
Fitting
u Only use saw blades the maximum permitted speed of
which is higher than the no-load speed of the power
tool.
Inserting/changing the circular saw blade
u Pull the plug out of the socket before carrying out any
work on the power tool.
u Wear protective gloves when fitting the saw blade.
Danger of injury when touching the saw blade.
u Only use saw blades that match the specifications
given in this operating manual and on the power tool
and that have been tested and marked in accordance
with EN847-1:2017.
u The permitted speed of the application tool must be at
least equal to the maximum speed marked on the
power tool. If accessories run faster than their rated
speed, they may break and fly off.
u Do not use abrasive wheels as the application tool un-
der any circumstances.
Selecting the saw blade
You will find an overview of recommended saw blades at the
end of these operating instructions.
Removing the saw blade (see figure A)
To change tools, we recommend that you place the power
tool down on the front side of the motor housing.
– Press and hold the spindle lock button (3).
u Do not press the spindle lock button (3) while the saw
spindle is moving. The power tool may become damaged
if this happens.
– Use the hex key (17) to undo the clamping bolt (18) in ro-
tational direction ➊.
– Swing the retracting blade guard (10) back and hold on
to it firmly.
– Remove the clamping flange (19) and the saw blade (20)
from the saw spindle (22).
Fitting the saw blade (see figure A)
To change tools, we recommend that you place the power
tool down on the front side of the motor housing.
– Clean the saw blade (20) and all the clamping elements
to be fitted.
– Swing the retracting blade guard (10) back and hold on
to it firmly.
– Place the saw blade (20) on the mounting flange (21).
The cutting direction of the teeth (direction of the arrow
on the saw blade) must match the rotational direction of
the arrow on the protective guard (10).
– Attach the clamping flange (19) and screw in the clamp-
ing bolt (18) in rotational direction ➋. Ensure that the
mounting flange (21) and clamping flange (19) are in-
stalled in the correct position.
– Press and hold the spindle lock button (3).
1 609 92A 4DH | (03.02.2021) Bosch Power Tools
