8
English
(2) Regarding the temperatures and charging time of the rechargeable battery
The temperatures and charging time will become as shown in Table 4.
Table 4
Charger
Battery
UC18YSL3
Charging voltage V 14.4 18
Type of battery Li-ion
Temperatures at which the battery can be
recharged
-10oC – 50oC
Charging time for battery capacity, approx.
(At 20oC)
1.3 Ah
1.5 Ah
2.0 Ah
2.5 Ah
3.0 Ah
4.0 Ah
5.0 Ah
6.0 Ah
min.
min.
min.
min.
min.
min.
min.
min.
15 (4
cells
)
15 (4
cells
)
20 (4
cells
)
25 (4
cells
)
20 (8
cells
) / 30 * BSL1430C
26 (8
cells
)
32 (8
cells
)
38 (8
cells
)
15 (5
cells
)
15 (5
cells
)
20 (5
cells
)
25 (5
cells
)
20 (10
cells
) / 30 * BSL1830C
26 (10
cells
)
32 (10
cells
)
38 (10
cells
)
NOTE
The recharging time may vary according to the ambient
temperature and power source voltage.
7. Disconnect the charger’s power cord from the
receptacle.
8. Hold the charger fi rmly and pull out the battery.
NOTE
Be sure to pull out the battery from the charger after use,
and then keep it.
Regarding electric discharge in case of new batteries,
etc.
As the internal chemical substance of new batteries and
batteries that have not been used for an extended period
is not activated, the electric discharge might be low when
using them the fi rst and second time. This is a temporary
phenomenon, and normal time required for recharging
will be restored by recharging the batteries 2 – 3 times.
How to make the batteries perform longer.
(1) Recharge the batteries before they become completely
exhausted.
When you feel that the power of the tool becomes
weaker, stop using the tool and recharge its battery. If
you continue to use the tool and exhaust the electric
current, the battery may be damaged and its life will
become shorter.
(2) Avoid recharging at high temperatures.
A rechargeable battery will be hot immediately after
use. If such a battery is recharged immediately after
use, its internal chemical substance will deteriorate, and
the battery life will be shortened. Leave the battery and
recharge it after it has cooled for a while.
CAUTION
○ If the battery is charged while it is heated because
it has been left for a long time in a location subject to
direct sunlight or because the battery has just been
used, the charge indicator lamp of the charger lights for
0.3 seconds, does not light for 0.3 seconds (off for 0.3
seconds). In such a case, fi rst let the battery cool, then
start charging.
○ When the charge indicator lamp fl ickers (at 0.2-second
intervals), check for and take out any foreign objects in
the charger’s battery connector. If there are no foreign
objects, it is probable that the battery or charger is
malfunctioning. Take it to your authorized Service
Center.
○ Since the built-in micro computer takes about
3 seconds to confi rm that the battery being charged with
UC18YSL3 is taken out, wait for a minimum of 3 seconds
before reinserting it to continue charging. If the battery
is reinserted within 3 seconds, the battery may not be
properly charged.
MOUNTING AND OPERATION
Action Figure Page
Removing and inserting the
battery
136
Charging 2 36
Mounting the bit 3 36
Reversing the rotational direction 4 36
Switch operation 5 37
Removing and mounting the hook 6 37
Remaining battery indicator 7 37
How to use the LED light
*1
837
Tightening mode selector function
*2
937
Charging a USB device from a
electrical outlet
10-a 38
Charging a USB device and
battery from a electrical outlet
10-b 38
How to recharge USB device 11 38
When charging of USB device is
completed
12 38
Selecting accessories ― 39
*1
How to use the LED light
NOTE
To prevent the battery power consumption caused
by forgetting to turn off the LED light, the light goes off
automatically in about 2 minutes.
*2 Tightening mode selector function
CAUTION
Select tightening mode while the trigger switch is
released. Failure to do so could result in malfunction.
0000BookWH14DBDL2.indb80000BookWH14DBDL2.indb8 2019/11/2013:56:532019/11/2013:56:53
