- 9 -
COOKING ZONE DIAMETER MINIMUM PAN DIAMETER
Ø 160 mm 110mm
Ø 200 mm 145mm
• BRIDGE FUNCTION
This feature allows you to connect, vertically, the two
cooking zones enlarging the area where to put the pots,
it is particularly suitable when it comes to cooking with
large pans. The function is activated by pressing the D
key areas of the two adjacent kitchenette, has been se-
lected is displayed to the side to display the symbols
and The power control of the cooking zone is only
enabled by the ring button and the area below. The
function can be disabled keys pressed together D.
• SPECIAL PROGRAMS
The cooktop has three special programs that can be set
by pressing the F key. The programs have already been
set and the temperatures are melting, working at 42
degrees to melt chocolate, butter or the like; warm-
ing, working at 70 degrees, when reheating previously
cooked; simmering, working at 94 degrees, to bring
to a boil slowly preparing sauces or soups and stews.
• SWITCHING THE COOKING AREA OFF
To switch a cooking zone off, press or crawl the E key of
the relative zone until reaching position .
• SWITCHING THE COOKING TOP OFF
To turn off the cooking top entirely hold down the A key.
• SAFETY SWITCH
The appliance has a safety switch that automatically
switches off the cooking zones when they have been
operating for a certain amount of time at a given power
level.
POWER LEVEL OPERATING TIME LIMIT (hours)
1 - 2 6
3 - 4 5
5 4
6 - 7 - 8 - 9 1,5
• MAINTENANCE
Remove any residues of food and drops of grease from
the cooking surface by using the special scraper supplied
on request (Fig.10).
Clean the heated area as thoroughly as possible using
suitable products, and a cloth/paper, then rinse with
water and dry with a clean cloth.
Using the special scraper immediately remove any
fragments of aluminium and plastic material that have
unintentionally melted on the heated cooking area, or
residues of sugar or food with a high sugar content.
In this way, any damage to the cooktop surface can be
prevented. Under no circumstances should abrasive
sponges, or corrosive chemical detergents, such as oven
sprays or stain removers, be used.
• WARNING: STEAM CLEANERS MUST NOT BE
USED.
DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European Directive 2002/96/EC on
Waste Electrical and Electronic Equipment
(WEEE), requires that old household
electrical appliances must not be disposed
of in the normal unsorted municipal waste
stream. Old appliances must be collected
separately in order to optimise the recovery and recycling
of the materials they contain and reduce the impact on
human health and the environment.
The crossed-out dustbin symbol on the product reminds
you of your obligation regarding separated waste
collection. Consumers should contact their local public
service or their local dealer for more information on the
correct disposal of exhausted household appliances.
THE MANUFACTURER DECLINES ALL
RESPONSIBILITY FOR EVENTUAL DAMAGES
CAUSED BY BREAKING THE ABOVE WARNINGS.
THE WARRANTY IS NOT VALID IN THE CASE OF
DAMAGE CAUSED BY FAILURE TO COMPLY WITH
THE ABOVE-MENTIONED WARNINGS.
