Digital laser measure with laser line

adapter

Operation

Activating the laser line

– Switch on the measuring tool (see "Switching the laser

measure on/off", page33).

– To show the laser line, briefly press the measuring button

(1). The indicator

flashes on the display.

u Do not direct the laser beam at persons or animals and

do not stare into the laser beam yourself (even from a

distance).

Note: If the measuring tool is switched on when fitting the ad-

apter, the laser will automatically switch off. Pressing the

measuring button (1) will reactivate the laser line.

Aligning the laser line

– Align the laser line with the level for horizontal alignment

(12) (see figure F) or the level for vertical alignment (11)

(rotate the measuring tool by 90°) (see figure G).

The bubble must be in the centre of the level vial.

– To precisely align the laser line, you can turn the adapter

head by ±10° around the laser line.

Note: Make sure that the measuring tool is always positioned

horizontally in order to obtain an exact measurement. You can

adjust the height of the laser line by placing suitable objects

underneath (e.g. a ladder, books, etc.).
