Makita JS 1670 [5/20] Additional safety rules

14. Maintain tools with care

Keep tools sharp and clean for better and safer

performance. Follow instructions for lubricating

and changing accessories. Inspect tool cords

periodically and, if damaged, have repaired by

authorized service facility. Inspect extension

cords periodically and replace if damaged. Keep

handles dry, clean and free from oil and grease.

15. Disconnect tools

When not in use, before servicing, and when

changing accessories such as blades, bits and

cutters.

16. Remove adjusting keys and wrenches

Form the habit of checking to see that keys and

adjusting wrenches are removed from tool before

turning it on.

17. Avoid unintentional starting

Don’t carry plugged-in tool with finger on switch.

Be sure switch is off when plugging in.

18. Outdoor use extension cords

When tool is used outdoors, use only extension

cords intended for use outdoors and so marked.

19. Stay alert

Watch what you are doing. Use common sense.

Do not operate tool when you are tired.

20. Check damaged parts

Before further use of the tool, a guard or other

part that is damaged should be carefully checked

to determine that it will operate properly and per-

form its intended function. Check for alignment of

moving parts, binding of moving parts, breakage

of parts, mounting, and any other conditions that

may affect its operation. A guard or other part

that is damaged should be properly repaired or

replaced by an authorized service center unless

otherwise indicated elsewhere in this instruction

manual. Have defective switches replaced by

and authorized service center. Do not use tool if

switch does not turn it on and off.

21. Warning

The use of any other accessory or attachment

other than recommended in this operating

instruction or the catalog may present a risk of

personal injury.

22. Have your tool repaired by an expert

This electric appliance is in accordance with the

relevant safety rules. Repairing of electric appli-

ances may be carried out only by experts other-

wise it may cause considerable danger for the

user.

ADDITIONAL SAFETY RULES

ENB011-2

1. Hold the tool firmly.

2. Secure the workpiece firmly.

3. Keep hands away from moving parts.

4. Edges and chips of the workpiece are sharp.

Wear gloves. It is also recommended that you

put on thickly bottomed shoes to prevent

injury.

5. Do not put the tool on the chips of the work-

piece. Otherwise it can cause damage and

trouble on the tool.

6. Do not leave the tool running. Operate the

tool only when hand-held.

7. Always be sure you have a firm footing. Be

sure no one is below when using the tool in

high locations.

8. Do not touch the blade or the workpiece

immediately after operation; they may be

extremely hot and could burn your skin.

9. Avoid cutting electrical wires. It can cause

serious accident by electric shock.

SAVE THESE INSTRUCTIONS.

OPERATING INSTRUCTIONS

Adjusting the blade clearance (Fig. 1 & 2)

For JS1660 Only

Important: Always be sure that the tool is switched off

and unplugged before adjusting the blade clearance.

Adjust the clearance between the side blade and the

center blade according to the thickness of the work-

piece. First use a screwdriver to loosen the screw.

Then use the hex wrench to adjust the clearance by

tightening or loosening the bolt. There may be a

slight difference between clearances (A) and (B).

Check the smaller clearance with the thickness

gauge and adjust it.

When using the thickness gauge to adjust the blade

clearance, refer to the table below.

After adjusting the clearance, tighten the screw

securely.

Lubrication (Fig. 3)

Before operation, lubricate the contact point of the

center blade and the pin. To keep good cutting perfor-

mance, also use a cutting lubricant from time to time

during operation.

Switch action (Fig. 4)

CAUTION:

Before plugging in the tool, always check to see that

the slide switch actuates properly and returns to the

“OFF” position when depressed.

To start the tool, move the slide switch forward, and

the slide switch will lock in the “ON” position. To stop,

lightly depress the rear of the slide switch, and it will

return to the “OFF” position.

Workpiece thickness

(mm)

Marking on

thickness gauge

Less than 0.8 0.5

0.8– 1.3 1.0

More than 1.3 1.5
