Zyxel GS-1116 EE [23/30] Front panel leds
![Zyxel GS-1116 EE [23/30] Front panel leds](/views2/1010742/page23/bg17.png)
Dimension GS-1116/GS-1124 Gigabit Switch
Hardware Description and Installation 2-7
Make sure the cable length between connections does not exceed 100
meters (328 feet).
2.4.5 Front Panel LEDs
The LEDs give real-time status information.
Figure 2-11 GS-1116 Front Panel LEDs
Figure 2-12 GS-1116 Front Panel LEDs
The following table provides LED descriptions.
Table 2-3 Network Cable Types
SPEED NETWORK CABLE TYPE
100Mbps 100Ω 2-pair UTP/STP Category 5
1000Mbps 100Ω 4-pair UTP/STP Category 5
